BMW 3 series E36 (1990-2000) instrument cluster rear defogger relay Wiring diagram
This page shows the only wiring diagram for the component.instrument cluster rear defogger relay, which is found in the car BMW 3 series E36 (1990-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram instrument cluster rear defogger relay (1 of 1)
2 5 318, 323, 328
ABS CONTROL MODULE/ HYDRAULIC UNIT
ANTI- THEFT CONTROL MODULE
AUTOMATIC CLIMATE CONTROL MODULE THERMOSTAT
AUTOMATIC TRANSMISSION RANGE SWITCH
AUXILIARY FUSE BOX (LEFT SIDE OF DASH)
BLOWER RELAY
BLU WIRE
COMPRESSOR CONTROL RELAY
DATA LINK CONNECTOR
DAYTIME RUNNING LAMPS MODULE
FROM
FROM FRONT POWER DISTRIBUTION BOX (DIAGRAM 2 OF 5)
FROM IGNITION SWITCH
FROM IGNITION SWITCH (DIAGRAM 3 OF 5)
FRONT POWER DISTRIBUTION BOX (LEFT REAR CORNER OF ENGINE COMPARTMENT)
FUSE
GRN WIRE
GRN/BLK WIRE
GRN/BLU WIRE
GRN/BLU/YEL WIRE
GRN/BRN WIRE
GRN/GRY WIRE
GRN/RED WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HIGH SPEED RELAY
HORN RELAY
INSTRUMENT CLUSTER
INSTRUMENT CLUSTER REAR DEFOGGER RELAY
JET HEATER THERMOSWITCH
LIGHT SWITCH
MULTI- FUNCTION CLOCK
NORMAL SPEED RELAY
PARK HEATING VENTILATION RELAY BOX (W/ PARK VENTILATION)
PROGRAM SWITCH
RED WIRE
RED/GRN WIRE
RED/GRY/YEL WIRE
REVERSING LIGHT SWITCH (W/O EGS)
ROLLOVER SENSOR MIRROR CONTROL SWITCH
SLIP CONTROL MODULE ASC SWITCH ABS RELAY
UNLOADER RELAY ON-BOARD COMPUTER MODULE
W/ ASC
W/O ASC
W/O AUTO CLIMATE CONTROL W/ AUTO CLIMATE CONTROL
WATER VALVE ASSEMBLY COMBINATION SWITCH
YEL WIRE
Go to component -> Power distribution circuit (4 of 5) -> INSTRUMENT CLUSTER REAR DEFOGGER RELAY
