BMW 3 series E36 (1990-2000) ground cyl 1-3 ks cyl 1-3 ks cyl 4-6 ks program volt Wiring diagrams
This page contains all the electrical diagrams for the component. ground cyl 1-3 ks cyl 1-3 ks cyl 4-6 ks program volt, in which he is found in the car BMW 3 series E36 (1990-2000). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram ground cyl 1-3 ks cyl 1-3 ks cyl 4-6 ks program volt (1 of 2)
A/C SYSTEM
ACTIVATE VALVE ACTIVATE RELAY
ACTIVATE VALVE CYL 4-6 KS GROUND CAMSHAFT POS
AIR PUMP (FRONT OF ENGINE COMPT)
ASC-SIG ZA ASC-SIG ZWV ASC-SIG MCR SENSOR SIGNAL
AUXILIARY FUSE BOX (LEFT SIDE OF DASH)
BATTERY
BLK WIRE
BLK/BLU WIRE
BRN WIRE
BRN/GRN WIRE
BRN/WHT WIRE
CAN LOW CAN HIGH BATTERY TXD
CRANKSHAFT POSITION/ RPM SENSOR (ON FRONT OF ENGINE)
CYL 1-3
CYL 4-6
DATA LINK CONNECTOR (RIGHT REAR OF ENGINE COMPT)
ENGINE CONTROL MODULE (DME) (RIGHT REAR CORNER OF ENGINE COMPT)
FUSE
GRN WIRE
GRN/BLU WIRE
GROUND CYL 1-3 KS CYL 1-3 KS CYL 4-6 KS PROGRAM VOLT
GRY/VIO WIRE
GRY/YEL WIRE
INSTRUMENT CLUSTER SYSTEM
NCA WIRE
OBD II CONNECTOR
ONLY
OXYGEN SENSOR I (IN FRONT OF CATALYTIC CONVERTER)
OXYGEN SENSOR II
OXYGEN SENSOR II OXYGEN SENSOR I (BEHIND CATALYTIC CONVERTER)
RED WIRE
RED/WHT WIRE
RED/WHT/YEL WIRE
RED/YEL WIRE
SECOND AIR PUMP RELAY
SLIP CONTROL MODULE (ABS/ASC) (BEHIND GLOVE BOX)
TRANSMISSION CONTROL MODULE (EGS) (RIGHT REAR CORNER OF ENGINE COMPT)
WHT WIRE
WHT/GRN WIRE
WHT/GRY WIRE
WHT/GRY/YEL WIRE
WHT/RED/YEL WIRE
WHT/VIO/YEL WIRE
WHT/YEL WIRE
YEL WIRE
YEL/BLU WIRE
Go to component -> Wiring diagram engine performance 2.5ls (2 of 2) -> GROUND CYL 1-3 KS CYL 1-3 KS CYL 4-6 KS PROGRAM VOLT
Wiring diagram ground cyl 1-3 ks cyl 1-3 ks cyl 4-6 ks program volt (2 of 2)
A/C SYSTEM
ACTIVATE VALVE ACTIVATE RELAY
ACTIVATE VALVE CYL 4-6 KS GROUND CAMSHAFT POS
AIR PUMP (FRONT OF ENGINE COMPT)
ASC-SIG ZA ASC-SIG ZWV ASC-SIG MCR SENSOR SIGNAL
AUXILIARY FUSE BOX (LEFT SIDE OF DASH)
BATTERY
BLK WIRE
BLK/BLU WIRE
BRN WIRE
BRN/GRN WIRE
BRN/WHT WIRE
CAN LOW CAN HIGH BATTERY TXD
CRANKSHAFT POSITION/ RPM SENSOR (ON FRONT OF ENGINE)
CYL 1-3
CYL 4-6
DATA LINK CONNECTOR (RIGHT REAR OF ENGINE COMPT)
ENGINE CONTROL MODULE (DME) (RIGHT REAR CORNER OF ENGINE COMPT)
FUSE
GRN WIRE
GRN/BLU WIRE
GROUND CYL 1-3 KS CYL 1-3 KS CYL 4-6 KS PROGRAM VOLT
GRY/VIO WIRE
GRY/YEL WIRE
INSTRUMENT CLUSTER SYSTEM
NCA WIRE
OBD II CONNECTOR
ONLY
OXYGEN SENSOR I (IN FRONT OF CATALYTIC CONVERTER)
OXYGEN SENSOR II
OXYGEN SENSOR II OXYGEN SENSOR I (BEHIND CATALYTIC CONVERTER)
RED WIRE
RED/WHT WIRE
RED/WHT/YEL WIRE
RED/YEL WIRE
SECOND AIR PUMP RELAY
SLIP CONTROL MODULE (ABS/ASC) (BEHIND GLOVE BOX)
TRANSMISSION CONTROL MODULE (EGS) (RIGHT REAR CORNER OF ENGINE COMPT)
WHT WIRE
WHT/GRN WIRE
WHT/GRY WIRE
WHT/GRY/YEL WIRE
WHT/RED/YEL WIRE
WHT/VIO/YEL WIRE
WHT/YEL WIRE
YEL WIRE
YEL/BLU WIRE
Go to component -> Wiring diagram engine performance 2.8ls (2 of 2) -> GROUND CYL 1-3 KS CYL 1-3 KS CYL 4-6 KS PROGRAM VOLT
