BMW 3 series E36 (1990-2000) fault ind sig battery volt m-prog ind gnd Wiring diagram

1995 VFTC AUTO AUTOMATIC TRANSMISSION RANGE SWITCH (IN CENTER CONSOLE, ON SHIFTER MECHANISM) B+ JUNCTION POINT BAND SOL CTRL HYD CTRL (-) GND BLK WIRE BLU WIRE BLU/BLK WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE BRAKE LIGHT SWITCH (ON BRACKET, ABOVE BRAKE PEDAL) BRAKE PDL POSIT BRN WIRE BRN/BLK WIRE BRN/ORG (OR BRN) WIRE BRN/VIO WIRE BRN/WHT WIRE CLOSED IN REVERSE POSITION CLR CLR 6 7 8 CRUISE CONTROL MODULE (TEMPOMAT) EGS WARNING LP FAULT IND SIG BATTERY VOLT M-PROG IND GND FRONT POWER DISTRIBUTION BOX (IN LEFT REAR CORNER OF ENGINE COMPARTMENT) FUSE GRN WIRE GRN/GRY WIRE GRN/WHT WIRE GRY WIRE GRY/BRN WIRE GRY/YEL WIRE HOT AT ALL TIMES HOT IN ACCY, RUN, START HOT IN RUN, START INSTRUMENT CLUSTER KICK DOWN SWITCH (LEFT FOOTWELL) MAN AUTO NCA WIRE OFF ORG/ WIRE OUTPUT SPEED (+) PROGRAM SWITCH MAN RED WIRE RPM SPEED SIG S-PROG IND KICK-DOWN SIG ASC SIG AUTO MODE SIG OIL TEMP SIG OIL TEMP SIG (+) SHIFT-LOCK SOL SOL VAL 1 CTRL TCC SOL CTRL SOL VAL 2 CTRL GND TRANSMISSION CONTROL MODULE (EGS) (ON RIGHT REAR CORNER OF ENGINE COMPT) VIO WIRE VIO/YEL WIRE WHT WIRE WHT/GRN/YEL WIRE YEL WIRE YEL/BLU WIRE YEL/BLU) YEL/BRN (OR WIRE YEL/GRN WIRE YEL/GRY WIRE YEL/WHT WIRE
