BMW 3 series E36 (1990-2000) convertible top storage lid microswitch Wiring diagram

15 20 DATA LINK CONNECTOR (RIGHT REAR SIDE OF ENGINE COMPT) 9 11 15 18 DIAG DIAG DRIVE AWAY PROTECT PWR SUPPLY BLK WIRE BLK/GRN WIRE BLU/GRY WIRE BODY ELECTRONICS CONTROL MODULE (ZKE IV) (BEHIND GLOVE BOX) BRN WIRE BRN/BLK WIRE CENTRAL LOCKING SWITCH CONV EX CONV CONVERTIBLE TOP STORAGE LID MICROSWITCH DRIVER'S DOOR LOCK SWITCH DRIVERS DOOR LOCK MOTOR ELECTRONIC IMMOBILIZER CONTROL MODULE (BEHIND GLOVE BOX) FRONT POWER DISTRIBUTION BOX (REAR LEFT SIDE OF ENGINE COMPARTMENT) GAS FILLER LOCK MOTOR GLOVE BOX LOCK MOTOR GRN WIRE GRN/WHT/YEL WIRE HOT AT ALL TIMES FUSE LEFT REAR DOOR LOCK MOTOR PASSENGERS DOOR LOCK MOTOR PASSENGERS DOOR LOCK SWITCH RED WIRE RED/BLK WIRE RED/GRN WIRE RED/GRN/YEL WIRE RIGHT REAR DOOR LOCK MOTOR SUPPLEMENTAL RESTRAINT SYSTEM CONTROL MODULE (BELOW REAR SEAT) TRUNK LID RELAY (BEHIND GLOVE BOX) (CONVERTIBLE ONLY) TRUNK LID SIG (CONV) DOOR SIG (4 DOOR) TRUNK LOCK MOTOR VIO/BLK WIRE WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/BRN/YEL WIRE WHT/GRN WIRE WHT/GRN/YEL WIRE WHT/GRY WIRE WHT/RED WIRE WHT/VIO WIRE WHT/YEL WIRE YEL WIRE
