Horn circuit for BMW 3 series GT F34 facelift (2015-2020)
Horn circuit
BLK WIRE
BLU/BLK WIRE
BLU/GRN WIRE
BRN WIRE
BRN/RED WIRE
ELECTRONIC STEERING WHEEL MODULE
ELECTRONICS JUNCTION BOX
FRONT ELECTRONIC MODULE
FUSE 10
FUSE 14
HIGH RANGE HORN
HORN BUTTON
HORN RELAY
HOT AT ALL TIMES
HOT W/ BI-STABLE RELAY ENERGIZED
LEFT SHIFT PADDLE
LOW RANGE HORN
NCA WIRE
RED/YEL WIRE
RIGHT END OF DASH)
RIGHT MULTI-FUNCTION STEERING WHEEL SWITCH BLOCK
RIGHT SHIFT PADDLE
STEERING COLUMN SWITCH CLUSTER
VIO/BLU WIRE
