BMW 3 series GT F34 facelift (2015-2020) central locking, hazard warning button switch operating unit wiring diagram
This page shows the only wiring diagram for the component.central locking, hazard warning button switch operating unit, which is found in the car BMW 3 series GT F34 facelift (2015-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
central locking, hazard warning button switch operating unit wiring diagram (1 of 1)
AUXILIARY BRAKE LIGHT
BACKUP LAMPS CIRCUIT
BLK/BLU WIRE
BLK/GRY WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/RED WIRE
BRAKE LIGHT
BRAKE LIGHT SWITCH
BRAKE/
BRN WIRE
BRN/BLK WIRE
BRN/BLU WIRE
CENTRAL LOCKING, HAZARD WARNING BUTTON SWITCH OPERATING UNIT
DIRECTION
DYNAMIC
GRN WIRE
GRN/BLK WIRE
GRN/RED WIRE
GRN/YEL WIRE
GRY/VIO WIRE
GT, SEDAN SPORTS WAGON
INTERFERENCE SUPPRESSOR FILTER 2
LEFT FOOTWELL)
LEFT INNER TAILLIGHT
LEFT OUTER TAILLIGHT
NOISE SUPPRESSOR FILTER
REAR WINDOW BUTTON
REVERSE
RIGHT INNER TAILLIGHT
TAIL
TAIL- LIGHT
TRAILER MODULE
TRAILER SOCKET
TURN
W/ TRAILER MODULE
W/O TRAILER MODULE
WHT WIRE
WHT/RED WIRE
WHT/YEL WIRE
YEL/BLK WIRE
YEL/VIO WIRE
Go to component -> Exterior lamps circuit, w/ led headlamps (2 of 3) -> CENTRAL LOCKING, HAZARD WARNING BUTTON SWITCH OPERATING UNIT
