Warning systems circuit, late production for BMW 3 series GT F34 (2011-2016)
Warning systems circuit, late production
BRN/BLK WIRE
COMPUTER DATA LINES SYSTEM
FUSE 104
HOT AT ALL TIMES
LEFT FOOTWELL)
LEFT FRONT ELECTRONIC WHEEL MODULE
LEFT FRONT ELECTRONIC WHEEL MODULE (ON LEFT FRONT WHEEL)
LEFT REAR ELECTRONIC WHEEL MODULE
LEFT REAR ELECTRONIC WHEEL MODULE (ON LEFT REAR WHEEL ASSEMBLY)
POWER DISTRIBUTION SYSTEM
REAR FUSE HOLDER
REAR FUSE HOLDER (RIGHT SIDE OF REAR COMPT)
RED/GRN WIRE
RED/GRY WIRE
REMOTE CONTROL RECEIVER
RIGHT FRONT ELECTRONIC WHEEL MODULE
RIGHT FRONT ELECTRONIC WHEEL MODULE (ON RIGHT FRONT WHEEL)
RIGHT REAR ELECTRONIC WHEEL MODULE
RIGHT REAR ELECTRONIC WHEEL MODULE (ON RIGHT REAR WHEEL ASSEMBLY)
WHT/BLU WIRE
