Contact-free tailgate opening circuit for BMW 3 series GT F34 (2011-2016)
Contact-free tailgate opening circuit
BLK WIRE
BLU/YEL WIRE
BRN WIRE
BUMPER AERIAL
CONTACT FREE TAILGATE OPENING EVALUATION ELECTRONICS
CONTACT-FREE TAILGATE OPENING LOWER SENSOR
CONTACT-FREE TAILGATE OPENING UPPER SENSOR
FRONT ELECTRONIC MODULE
FRONT ELECTRONIC MODULE (RIGHT END OF DASH)
FUSE 150
GRY/BLK WIRE
GRY/RED WIRE
HOT W/ BISTABLE RELAY ENERGIZED
POWER DISTRIBUTION SYSTEM
REAR FUSE HOLDER
REAR FUSE HOLDER (RIGHT SIDE OF REAR COMPT)
RED/GRY WIRE
RIGHT END OF DASH)
