Sport seats circuit for BMW 3 series GT F34 (2011-2016)
Sport seats circuit
BLK WIRE
BLK/BLU WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER LUMBAR SUPPORT VALVE BLOCK
DRIVER LUMBAR SUPPORT VALVE BLOCK (LEFT SIDE OF DRIVER SEAT BACK)
DRIVER'S SEAT BACKREST WIDTH ADJUSTMENT SWITCH
DRIVER'S SEAT BACKREST WIDTH ADJUSTMENT VALVE BLOCK
DRIVER'S SEAT MODULE
DRIVER'S SEAT PNEUMATIC PUMP
DRIVER'S SIDE SEAT ADJUSTMENT SWITCH BLOCK
DRIVERS SEAT MODULE (UNDER DRIVER SEAT)
FRONT PASSENGER'S LUMBAR SUPPORT VALVE BLOCK
FRONT PASSENGER'S LUMBAR SUPPORT VALVE BLOCK (RIGHT SIDE OF PASSENGER SEAT BACK)
FRONT PASSENGER'S SEAT BACKREST WIDTH ADJUSTMENT SWITCH
FRONT PASSENGER'S SEAT BACKREST WIDTH ADJUSTMENT VALVE BLOCK
FRONT PASSENGER'S SEAT PNEUMATIC PUMP
FRONT PASSENGER'S SIDE SEAT ADJUSTMENT SWITCH BLOCK
FRONT POWER DISTRIBUTION BOX
FRONT POWER DISTRIBUTION BOX (RIGHT REAR OF ENGINE COMPT)
FUSE 27
FUSE 27 FUSE 68
FUSE 68
GRN WIRE
LEFT FOOTWELL)
ORG/GRN WIRE
RED WIRE
RED/BLU WIRE
RED/YEL WIRE
RELAY ENERGIZED
WHT WIRE
YEL WIRE
YEL/BLU WIRE
YEL/WHT WIRE
