Parking assistant circuit, w/o parking maneuvering assistant for BMW 3 series GT F34 (2011-2016)
Parking assistant circuit, w/o parking maneuvering assistant
BLU/BLK WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/RED WIRE
BRN WIRE
BRN/BLK WIRE
BRN/WHT WIRE
CENTER CONSOLE OPERATING UNIT
COMPUTER DATA LINES SYSTEM
FUSE 500
FUSE BOX
GRN/BLK WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
INTEGRATED CHASSIS MANAGEMENT
LEFT FRONT CENTER ULTRASONIC SENSOR
LEFT FRONT OUTER ULTRASONIC SENSOR
LEFT REAR CENTER ULTRASONIC SENSOR
LEFT REAR OUTER ULTRASONIC SENSOR
REAR ELECTRONIC MODULE
RED WIRE
RIGHT FRONT CENTER ULTRASONIC SENSOR
RIGHT FRONT OUTER ULTRASONIC SENSOR
RIGHT REAR CENTER ULTRASONIC SENSOR
RIGHT REAR OUTER ULTRASONIC SENSOR
YEL/BLK WIRE
YEL/BLU WIRE
YEL/BRN WIRE
YEL/GRN WIRE
YEL/GRY WIRE
YEL/RED WIRE
