All around vision camera circuit for BMW 3 series GT F34 (2011-2016)
All around vision camera circuit
4 3 2 1 5 EXTERIOR MIRROR CAMERA
ALL ROUND VISION CAMERA
ALL ROUND VISION CAMERA (LEFT KICK PANEL)
BLU WIRE
BRN WIRE
BRN/WHT WIRE
CENTER CONSOLE OPERATING UNIT
COMPUTER DATA LINES SYSTEM
DRIVER'S EXTERIOR MIRROR
EXTERIOR MIRROR CAMERA
FRONT PASSENGER'S EXTERIOR MIRROR
FUSE 154
FUSE 154 FUSE HOLDER (RIGHT SIDE OF REAR COMPT)
GRN WIRE
GRN/BLU WIRE
GRN/RED WIRE
GRN/YEL WIRE
HEAD UNIT
HOT W/ TERMINAL
INTEGRATED CHASSIS MANAGEMENT
INTEGRATED CHASSIS MANAGEMENT (UNDER CENTER CONSOLE)
LEFT BUMPER CAMERA
LEFT BUMPER CAMERA (FRONT OF LEFT FRONT WHEELWELL)
NCA WIRE
ORG/ WIRE
ORG/GRN WIRE
REAR
REAR FUSE HOLDER
RED WIRE
REVERSING CAMERA (CENTER REAR OF TRUNK LID)
RIGHT BUMPER CAMERA
RIGHT BUMPER CAMERA (FRONT OF RIGHT FRONT WHEELWELL)
W/ CIC
W/O CIC
WHT WIRE
YEL/BLU WIRE
