Heated mirrors circuit, with lin bus function for BMW 3 series GT F34 (2011-2016)
Heated mirrors circuit, with lin bus function
BLU/YEL WIRE
BRN WIRE
CAN L
COMPUTER DATA LINES SYSTEM
DRIVER EXTERIOR MIRROR
DRIVER'S DOOR SWITCH BLOCK
FRONT ELECTRONIC MODULE (RIGHT END OF DASH)
FRONT PASSENGER EXTERIOR MIRROR
FRONT POWER DISTRIBUTION BOX (RIGHT REAR OF ENGINE COMPT)
GRN WIRE
HOT AT ALL TIMES FUSE BOX FUSE 504
HOT W/
LEFT FOOTWELL)
LIN BUS SIG
MIRROR HEATING
ORG/GRN WIRE
RED WIRE
RED/GRY WIRE
RED/YEL WIRE
RELAY ENERGIZED FUSE 22
SUPPLY
WHT/BRN WIRE
YEL WIRE
