BMW 3 series GT F34 (2011-2016) right front electronic wheel module wiring diagram
This page shows the only wiring diagram for the component.right front electronic wheel module, which is found in the car BMW 3 series GT F34 (2011-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
right front electronic wheel module wiring diagram (1 of 1)
BRN/BLK WIRE
COMPUTER DATA LINES SYSTEM
FUSE 104
HOT AT ALL TIMES
LEFT FOOTWELL)
LEFT FRONT ELECTRONIC WHEEL MODULE
LEFT FRONT ELECTRONIC WHEEL MODULE (ON LEFT FRONT WHEEL)
LEFT REAR ELECTRONIC WHEEL MODULE
LEFT REAR ELECTRONIC WHEEL MODULE (ON LEFT REAR WHEEL ASSEMBLY)
POWER DISTRIBUTION SYSTEM
REAR FUSE HOLDER
REAR FUSE HOLDER (RIGHT SIDE OF REAR COMPT)
RED/GRN WIRE
RED/GRY WIRE
REMOTE CONTROL RECEIVER
RIGHT FRONT ELECTRONIC WHEEL MODULE
RIGHT FRONT ELECTRONIC WHEEL MODULE (ON RIGHT FRONT WHEEL)
RIGHT REAR ELECTRONIC WHEEL MODULE
RIGHT REAR ELECTRONIC WHEEL MODULE (ON RIGHT REAR WHEEL ASSEMBLY)
WHT/BLU WIRE
Go to component -> Warning systems circuit, late production -> RIGHT FRONT ELECTRONIC WHEEL MODULE
