BMW 2 series G42 (2021-2024) light operating unit night vision button Wiring diagram
This page shows the only wiring diagram for the component.light operating unit night vision button, which is found in the car BMW 2 series G42 (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram light operating unit night vision button (1 of 1)
AIR CONDITIONING
AUXILIARY TURN SIGNAL LAMP
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BLU/RED WIRE
BLU/VIO WIRE
BODY DOMAIN CONTROLLER (RIGHT KICK PANEL)
BRN WIRE
BRN/BLK WIRE
COMPUTER DATA LINES SYSTEM
DRIVER VEHICLE EXTERIOR MIRROR
FRONT PASSENGER VEHICLE EXTERIOR MIRROR
FUSE 1
FUSE 39
GRN/BLU WIRE
GRN/GRY WIRE
GRY/VIO WIRE
HOT AT ALL TIMES
HOT W/ BI-STABLE RELAY ENERGIZED
LIGHT OPERATING UNIT NIGHT VISION BUTTON
ORG/ WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT POWER DISTRIBUTION BOX
STEERING COLUMN SWITCH CLUSTER
TRAILER MODULE
VIO/RED WIRE
WHT/GRY WIRE
WHT/VIO WIRE
YEL/BLK WIRE
YEL/WHT WIRE
Go to component -> Exterior lamps circuit (1 of 3) -> LIGHT OPERATING UNIT NIGHT VISION BUTTON
