BMW 2 series G42 (2021-2024) left multi-function steering column switch Wiring diagram
This page shows the only wiring diagram for the component.left multi-function steering column switch, which is found in the car BMW 2 series G42 (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left multi-function steering column switch (1 of 1)
2.0L TURBO COUPE, 3.0L TURBO
ACCELERATOR PEDAL MODULE
BLK/VIO WIRE
BLU WIRE
BLU/RED WIRE
BODY DOMAIN CONTROLLER
BRAKE LIGHT SWITCH
BRN WIRE
BRN/BLK WIRE
BRN/GRN WIRE
CENTER CONSOLE CONTROL CENTER
COMPUTER DATA LINES SYSTEM
COUPE, GRAN COUPE
DIGITAL MOTOR ELECTRONICS
ELECTROMOTIVE THROTTLE ACTUATOR (ON THROTTLE BODY)
FUSE 14
GEAR SELECTOR SWITCH
GROUND DISTRIBUTION SYSTEM
HOT W/ VALVETRONIC RELAY ENERGIZED
INTEGRATED SUPPLY MODULE
LEFT MULTI-FUNCTION STEERING COLUMN SWITCH
NCA WIRE
PWM BFI
RED WIRE
RED/GRN WIRE
RED/WHT WIRE
RIGHT MULTI-FUNCTION STEERING WHEEL SWITCH
STEERING COLUMN SWITCH CLUSTER
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/VIO WIRE
WHT/YEL WIRE
YEL WIRE
YEL/GRN WIRE
YEL/WHT WIRE
Go to component -> Cruise control circuit -> LEFT MULTI-FUNCTION STEERING COLUMN SWITCH
