BMW 2 series F22/F23 facelift (2017-2021) w/ extendable thigh support w/o extendable thigh support Wiring diagrams

This page contains all the electrical diagrams for the component. w/ extendable thigh support w/o extendable thigh support, in which he is found in the car BMW 2 series F22/F23 facelift (2017-2021). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram w/ extendable thigh support w/o extendable thigh support (1 of 2)

Wiring diagram w/ extendable thigh support w/o extendable thigh support for BMW 2 series F22/F23 facelift (2017-2021)

Get access

BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DRIVER THIGH SUPPORT HEATING DRIVER'S SEAT BACKREST HEATING DRIVER'S SEAT MODULE DRIVER'S SEAT SURFACE HEATING FRONT PASSENGER SEAT MODULE FRONT PASSENGER THIGH SUPPORT HEATING FRONT PASSENGER'S SEAT BACKREST HEATING FRONT POWER DISTRIBUTION BOX FUSE 67 FUSE 68 GRN WIRE GRN/VIO WIRE GRY WIRE HEATING/AIR CONDITIONING SYSTEM K-CAN BUS SIG NCA WIRE ORG/GRN WIRE PASSENGER'S SEAT CUSHION HEATING RED WIRE RED/BLU WIRE RED/BRN WIRE RELAY ENERGIZED VIO WIRE W/ EXTENDABLE THIGH SUPPORT W/O EXTENDABLE THIGH SUPPORT WHT WIRE YEL/BRN WIRE YEL/RED WIRE

Go to component: -> Front heated seats circuit, w/ memory -> W/ EXTENDABLE THIGH SUPPORT W/O EXTENDABLE THIGH SUPPORT

Wiring diagram w/ extendable thigh support w/o extendable thigh support (2 of 2)

Wiring diagram w/ extendable thigh support w/o extendable thigh support for BMW 2 series F22/F23 facelift (2017-2021)

Get access

BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DRIVER THIGH SUPPORT HEATING DRIVER'S SEAT BACKREST HEATING DRIVER'S SEAT HEATING ELECTRONICS DRIVER'S SEAT SURFACE HEATING EARLY PRODUCTION FRONT PASSENGER SEAT HEATING ELECTRONICS FRONT PASSENGER THIGH SUPPORT HEATING FRONT PASSENGER'S SEAT BACKREST HEATING FRONT POWER DISTRIBUTION BOX FUSE 64 FUSE 65 GRN WIRE GRN/VIO WIRE GRY WIRE HEATING/AIR CONDITIONING SYSTEM K-CAN BUS SIG LATE PRODUCTION NCA WIRE PASSENGER'S SEAT CUSHION HEATING RED WIRE RED/BLU WIRE RELAY ENERGIZED VIO WIRE W/ EXTENDABLE THIGH SUPPORT W/O EXTENDABLE THIGH SUPPORT WHT/BRN WIRE YEL/BRN WIRE YEL/RED WIRE

Go to component: -> Front heated seats circuit, w/o memory -> W/ EXTENDABLE THIGH SUPPORT W/O EXTENDABLE THIGH SUPPORT
