BMW 2 series F22/F23 facelift (2017-2021) term 15 Wiring diagram
This page shows the only wiring diagram for the component.term 15, which is found in the car BMW 2 series F22/F23 facelift (2017-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram term 15 (1 of 1)
A/T
BATTERY
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BRN WIRE
BLU/RED WIRE
BRN WIRE
BRN/BLK WIRE
CHARGING CIRCUIT
CLUTCH MODULE
CLUTCH SIG
COMPUTER DATA LINES SYSTEM
DIGITAL MOTOR ELECTRONICS
ELECTRONIC TRANSMISSION CONTROL
ENG START SIG
FLEX BUS SIG
FRONT ELECTRONIC MODULE
FRONT POWER DISTRIBUTION BOX
FUSE 21
FUSE 57
GRN WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
HOT W/ TERMINAL
INTELLIGENT BATTERY SENSOR
JUMP START TERMINAL POINT
LED ACT
M/T
NCA WIRE
PNK WIRE
PT-CAN BUS SIG
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
SAFETY BATTERY TERMINAL GAS GENERATOR
SIG
SPLY
SPLY TERM 15
START-STOP BUTTON
START/ STOP SW
STARTER
TERM 15
TRANSFER TERMINAL POINT
VIO/YEL WIRE
WHT WIRE
WHT/VIO WIRE
YEL WIRE
Go to component: -> Starting circuit -> TERM 15
