BMW 2 series F22/F23 facelift (2017-2021) front passenger's seat backrest width adjustment valve block Wiring diagram

This page shows the only wiring diagram for the component.front passenger's seat backrest width adjustment valve block, which is found in the car BMW 2 series F22/F23 facelift (2017-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram front passenger's seat backrest width adjustment valve block (1 of 1)

Wiring diagram front passenger's seat backrest width adjustment valve block for BMW 2 series F22/F23 facelift (2017-2021)

Get access

BLK WIRE BLK/BLU WIRE BLK/WHT WIRE BLK/YEL WIRE BRN WIRE BRN/YEL WIRE DRIVER LUMBAR SUPPORT VALVE BLOCK DRIVER'S SEAT BACKREST WIDTH ADJUSTMENT VALVE BLOCK DRIVER'S SEAT LUMBAR SUPPORT SWITCH DRIVER'S SEAT PNEUMATIC PUMP DRIVER'S SIDE SEAT ADJUSTMENT SWITCH BLOCK FRONT PASSENGER LUMBAR SUPPORT SWITCH FRONT PASSENGER LUMBAR SUPPORT VALVE BLOCK FRONT PASSENGER SEAT PNEUMATIC PUMP FRONT PASSENGER SIDE SEAT ADJUSTMENT SWITCH BLOCK FRONT PASSENGER'S SEAT BACKREST WIDTH ADJUSTMENT VALVE BLOCK FRONT POWER DISTRIBUTION BOX FUSE 27 RED WIRE RELAY ENERGIZED W/ ELECTRIC SEAT ADJUSTMENT W/O ELECTRIC SEAT ADJUSTMENT YEL WIRE

Go to component: -> Lumbar circuit -> FRONT PASSENGER'S SEAT BACKREST WIDTH ADJUSTMENT VALVE BLOCK
