BMW 2 series F22/F23 facelift (2017-2021) driver's seat belt tensioner gas generator Wiring diagram
This page shows the only wiring diagram for the component.driver's seat belt tensioner gas generator, which is found in the car BMW 2 series F22/F23 facelift (2017-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver's seat belt tensioner gas generator (1 of 1)
AIR BAG SENS
BLK WIRE
BLU WIRE
BLU/GRY WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
BRN/BLK WIRE
DRIVER SEAT POSITION SENSOR
DRIVER SIDE AIR BAG GAS GENERATOR
DRIVER'S SEAT BELT BUCKLE CONTACT
DRIVER'S SEAT BELT TENSIONER GAS GENERATOR
ELECTRIC FUEL PUMP CONTROL ELECTRONICS
FRONT PASSENGER SEAT POSITION SENSOR
GRY/YEL WIRE
LEFT "B" PILLAR AIR BAG SENSOR
PASSENGER'S SEAT BELT BUCKLE CONTACT
RED WIRE
RIGHT "B" PILLAR AIR BAG SENSOR
RIGHT HEAD AIR BAG GAS GENERATOR
VIO WIRE
VIO/YEL WIRE
W/ OPTIONAL EXTRAS
W/O MEMORY
WHT WIRE
YEL WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> Supplemental restraints circuit, coupe (2 of 3) -> DRIVER'S SEAT BELT TENSIONER GAS GENERATOR
