Car Wiring Diagrams for Base radio circuit, w/o active sound design for BMW 2 series Gran Coupe F44 (2019-2024)

BLK/GRN WIRE BLU/BLK WIRE BLUETOOTH AERIAL BRN/ORG WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DIVERSITY ANTENNA 2 FRONT POWER DISTRIBUTION BOX FUSE 64 FUSE 85 GPS ANTENNA GRN WIRE GRY/BLK WIRE GRY/BRN WIRE GRY/RED WIRE HEAD UNIT (CENTER OF DASH) HOT W/ TERMINAL MICROPHONE 2 (RIGHT FRONT OF HEADLINER) NCA WIRE NFC NEAR- FIELD COMMUNICATION REAR WINDOW ANTENNA RED/BLU WIRE RED/GRY WIRE SDARS ANTENNA TELEPHONE ANTENNA VIO WIRE W/ TELEMATICS W/O TELEMATICS WHT WIRE WHT/BLK WIRE WHT/BRN WIRE WHT/RED WIRE WIRELESS CHARGING STORAGE (FRONT OF CENTER CONSOLE) YEL WIRE YEL/BLK WIRE YEL/RED WIRE

AUDIO CONTROL PANEL BLK/GRN WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BODY DOMAIN CONTROLLER BRN WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM EMERGENCY LOUDSPEAKER FRONT CENTER VENTILATION GRILLE FUSE 1 GPS ANTENNA GRN WIRE GRN/BLU WIRE GRY/BRN WIRE HOT W/ BI-STABLE RELAY ENERGIZED MICROPHONE (W/O TELEMATICS) (LEFT FRONT OF HEADLINER) NCA WIRE RED/YEL WIRE ROOF ANTENNA (TOP REAR CENTER OF ROOF) TELEMATIC COMMUNICATION BOX (CENTER REAR OF ROOF) TELEMATICS ANTENNA TELEPHONE ANTENNA VIO WIRE W/ TELEMATICS W/O TELEMATICS WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/RED WIRE

BLK/GRN WIRE BLK/YEL WIRE BLU/BLK WIRE GRN WIRE GRN/BLU WIRE GRY/BRN WIRE LEFT FRONT BASS SPEAKER LEFT FRONT MID-RANGE SPEAKER LEFT REAR MID-RANGE SPEAKER MICROPHONE (W/ TELEMATICS) (LEFT FRONT OF HEADLINER) NCA WIRE RIGHT FRONT BASS SPEAKER RIGHT FRONT MID-RANGE SPEAKER RIGHT REAR MID-RANGE SPEAKER VIO/YEL WIRE WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/RED WIRE

BLK WIRE BLU WIRE BLUETOOTH ANTENNA BRN WIRE BRN/BLK WIRE CENTRAL INFORMATION DISPLAY COMPUTER DATA LINES SYSTEM CONTROLLER (IDRIVE) FRONT POWER DISTRIBUTION BOX FUSE 68 GRN WIRE GRN/BLU WIRE HEAD UNIT (CENTER OF DASH) HOT W/ TERMINAL NCA WIRE ORG/ WIRE RED WIRE RED/BLK WIRE RED/YEL WIRE VIO WIRE WHT WIRE WHT/BLU WIRE WLAN ANTENNA
