BMW 2 series Gran Coupe F44 (2019-2024) tailgate button vehicle interior wiring diagram
This page shows the only wiring diagram for the component.tailgate button vehicle interior, which is found in the car BMW 2 series Gran Coupe F44 (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
tailgate button vehicle interior wiring diagram (1 of 1)
BLK/WHT WIRE
BLU WIRE
BODY DOMAIN CONTROLLER (RIGHT KICK PANEL)
BRN WIRE
BRN/BLK WIRE
BRN/ORG WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S DOOR CENTRAL LOCKING BUTTON
DRIVER'S DOOR POWER WINDOW DRIVE W/ CONTROL ELECTRONICS
DRIVER'S DOOR SIDE REAR POWER WINDOW DRIVE W/ CONTROL ELECTRONICS
DRIVER'S SIDE REAR POWER WINDOW SWITCH
FRONT INTERIOR LIGHT
FRONT PASSENGER DOOR LOCKING BUTTON
FRONT PASSENGER DOOR POWER WINDOW DRIVE W/ CONTROL ELECTRONICS
FRONT PASSENGER DOOR POWER WINDOW SWITCH
FRONT POWER DISTRIBUTION BOX
FUSE 1
FUSE 43
FUSE 44
FUSE 47
GRY/RED WIRE
HOT AT ALL TIMES
HOT W/ BI-STABLE RELAY ENERGIZED
LIGHT OPERATING UNIT
NCA WIRE
REAR PASSENGER DOOR POWER WINDOW SWITCH
REAR PASSENGER SIDE POWER WINDOW DRIVE W/ CONTROL ELECTRONICS
RED WIRE
RED/BLU WIRE
RED/GRY WIRE
RED/YEL WIRE
TAILGATE BUTTON VEHICLE INTERIOR
USB CHARGING SOCKET
USB CHARGING SOCKET 3
WHT/BLU WIRE
WHT/VIO WIRE
WHT/YEL WIRE
YEL/BLU WIRE
Go to component -> Instrument illumination circuit -> TAILGATE BUTTON VEHICLE INTERIOR
