BMW 2 series Gran Coupe F44 (2019-2024) rear passenger side inside door handle light Wiring diagram
This page shows the only wiring diagram for the component.rear passenger side inside door handle light, which is found in the car BMW 2 series Gran Coupe F44 (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear passenger side inside door handle light (1 of 1)
BLK/YEL WIRE
BLU WIRE
BOARD PASSENGER'S SIDE LIGHTING DECORATIVE STRIP DASH
CENTER DRIVER'S DOOR TRIM PANEL LIGHTING
CENTER DRIVER'S SIDE REAR DOOR TRIM PANEL LIGHTING
CENTER FRONT PASSENGER DOOR TRIM PANEL LIGHTING
CENTER REAR PASSENGER'S SIDE DOOR TRIM PANEL LIGHTING
CENTER STACK LIGHTING
DRIVER'S DOOR CONTOUR LIGHTING
DRIVER'S DOOR INSIDE DOOR HANDLE LIGHT
DRIVER'S DOOR TRIM PANEL LIGHTING
DRIVER'S SIDE REAR DOOR CONTOUR LIGHTING
DRIVER'S SIDE REAR INSIDE DOOR HANDLE LIGHT
FRONT PASSENGER DOOR CONTOUR LIGHTING
FRONT PASSENGER DOOR INSIDE DOOR HANDLE LIGHT
FRONT PASSENGER SIDE REAR DOOR CONTOUR LIGHTING
GRN/BLU WIRE
LIGHT
LIGHT SOURCE 1
LIGHT SOURCE 2
LIGHT SOURCE 3
LIGHT SOURCE 4
LIGHT SOURCE 5
LIGHT SOURCE 6
NCA WIRE
REAR PASSENGER SIDE INSIDE DOOR HANDLE LIGHT
RED WIRE
RED/BLK WIRE
RED/VIO WIRE
SOURCE 3
VIO WIRE
W/ DECORATION, LIGHT PACKAGE
W/ INTERIOR LIGHT PACKAGE
WHT WIRE
WHT/BLU WIRE
WHT/RED WIRE
WHT/VIO WIRE
WHT/YEL WIRE
YEL/BLU WIRE
Go to component -> Computer data lines circuit (5 of 6) -> REAR PASSENGER SIDE INSIDE DOOR HANDLE LIGHT
