Car Wiring Diagrams for Trunk & fuel door release circuit for BMW 1 series F20/F21 (2011-2015)

BLK WIRE BLU WIRE BRN WIRE BRN/BLK WIRE CAR ACCESS SYSTEM (UNDER LEFT SIDE OF DASH) COMPUTER DATA LINES SYSTEM COUPE CONVERTIBLE ELECTRONICS JUNCTION BOX FUEL FILLER FLAP CENTRAL LOCKING DRIVE (RIGHT SIDE OF REAR COMPT) FUSE GRN WIRE GRY/BRN WIRE GRY/GRN WIRE GRY/RED WIRE GRY/YEL WIRE HOT AT ALL TIMES HOTEL SWITCH JUNCTION BOX (UNDER RIGHT SIDE OF DASH) ORG/GRN WIRE REAR LID RELEASE SWITCH (INTERIOR) TRUNK LID BUTTON TRUNK LID CENTRAL LOCKING DRIVE WHT/BRN WIRE YEL/BLU WIRE YEL/RED WIRE
