Car Wiring Diagrams for Heated seats circuit, without memory for BMW 1 series F20/F21 (2011-2015)

BLU WIRE BLU/VIO WIRE BLU/WHT WIRE BRN WIRE CENTER CONSOLE SWITCH CENTER DRIVER'S SEAT BACKREST HEATING ELEMENT (IN DRIVER SEAT BACK) DRIVER'S SEAT CUSHION HEATING ELEMENT (IN DRIVER SEAT CUSHION) DRIVER'S SEAT HEATING MODULE (UNDER DRIVER SEAT) ELECTRONICS JUNCTION BOX FUSE 10 FUSE 3 FUSE 68 GRN WIRE GRN/BRN WIRE GRN/RED WIRE HEATING/AIR CONDITIONING HOT AT ALL TIMES HOT W/ TERMINAL 15 RELAY ENERGIZED JUNCTION BOX (UNDER RIGHT SIDE OF DASH) NCA WIRE PASSENGER'S SEAT BACKREST HEATING ELEMENT (IN PASSENGER SEAT BACK) PASSENGER'S SEAT CUSHION HEATING ELEMENT (IN PASSENGER SEAT CUSHION) PASSENGER'S SEAT HEATING MODULE (UNDER FRONT PASSENGER'S SEAT) RED WIRE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE RELAY ENERGIZED FUSE 77 SYSTEM (CENTER OF DASH, ABOVE RADIO) VIO WIRE WHT WIRE WHT/BLU WIRE WHT/YEL WIRE YEL WIRE
