BMW 1 series F20/F21 (2011-2015) w/o interference suppression filter Wiring diagram
This page shows the only wiring diagram for the component.w/o interference suppression filter, which is found in the car BMW 1 series F20/F21 (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/o interference suppression filter (1 of 1)
AF INTERFERENCE SUPPRESSOR FILTER (LEFT SIDE OF REAR WINDOW PANEL)
AUXILIARY BRAKE LIGHT
BACKUP LAMPS CIRCUIT
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLK/VIO WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/RED WIRE
BRAKE/
BRN WIRE
BRN/BLK WIRE
BRN/BLU WIRE
FOG
GRN WIRE
GRN/RED WIRE
GRN/YEL WIRE
GRY/BLU WIRE
GRY/VIO WIRE
GRY/YEL WIRE
HAZARD WARNING SWITCH
LEFT TAILLIGHT
ORG/GRN WIRE
PARK
RED/BLU WIRE
RED/VIO WIRE
RED/YEL WIRE
REVERSE
RIGHT TAILLIGHT
TURN
W/ INTERFERENCE SUPPRESSION FILTER
W/ XENON
W/O INTERFERENCE SUPPRESSION FILTER
YEL WIRE
YEL/BLK WIRE
YEL/WHT WIRE
Go to component: -> Exterior lamps & trailer connector circuit (2 of 3) -> W/O INTERFERENCE SUPPRESSION FILTER
