BMW 1 series F20/F21 (2011-2015) wind screen cowl panel latch incremental transducer drive unit Wiring diagram

This page shows the only wiring diagram for the component.wind screen cowl panel latch incremental transducer drive unit, which is found in the car BMW 1 series F20/F21 (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram wind screen cowl panel latch incremental transducer drive unit (1 of 1)

Wiring diagram wind screen cowl panel latch incremental transducer drive unit for BMW 1 series F20/F21 (2011-2015)

Get access

BLK/GRN WIRE BLK/RED WIRE BRN WIRE CAR ACCESS SYSTEM (UNDER LEFT SIDE OF DASH) CLAMPING BRACKET ERECTED HALL SENSOR CLAMPING BRACKET TAKEN DOWN HALL SENSOR CONVERTIBLE TOP COMPARTMENT FLOOR SWITCH (LEFT FRONT OF REAR COMPT) CONVERTIBLE TOP COMPARTMENT LID LOCKED SWITCH COWL PANEL LOCKED HALL SENSOR GRN/WHT WIRE LOCKING COWL PANEL DRIVE (CENTER FRONT OF ROOF) MAIN PILLAR ERECTED HALL SENSOR MAIN PILLAR TAKEN DOWN HALL SENSOR NCA WIRE RED WIRE TENSIONING BAR EXTENDED HALL SENSOR WHT/BRN WIRE WHT/YEL WIRE WIND SCREEN COWL PANEL LATCH INCREMENTAL TRANSDUCER DRIVE UNIT YEL WIRE YEL/BLU WIRE YEL/BRN WIRE YEL/RED WIRE

Go to component: -> Convertible top circuit (2 of 2) -> WIND SCREEN COWL PANEL LATCH INCREMENTAL TRANSDUCER DRIVE UNIT
