BMW 1 series F20/F21 (2011-2015) w/ automatic start/stop function w/o automatic start/stop function Wiring diagrams

This page contains all the electrical diagrams for the component. w/ automatic start/stop function w/o automatic start/stop function, in which he is found in the car BMW 1 series F20/F21 (2011-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram w/ automatic start/stop function w/o automatic start/stop function (1 of 6)

Wiring diagram w/ automatic start/stop function w/o automatic start/stop function for BMW 1 series F20/F21 (2011-2015)

Get access

AMPLIFIER (LEFT SIDE OF ANTENNA DIVERSITY (IF EQUIPPED) BLK WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE BRN/ORG WIRE BRN/WHT WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM CONTROLLER COUPE CONVERTIBLE DASH) FM ANTENNA 2 ANTENNA (CONVERTIBLE) (CONVERTIBLE) FM ANTENNA 3 (CONVERTIBLE) FUSE FUSE 15 GRN WIRE GRY WIRE HOT AT ALL TIMES JUNCTION BOX (UNDER RIGHT SIDE OF LEFT FRONT MID-RANGE SPEAKER LEFT FRONT TWEETER LEFT REAR HI-RANGE SPEAKER LEFT SIDE TRIM PANEL MID-RANGE SPEAKER LEFT SUBWOOFER NCA WIRE ORG/GRN WIRE POWER DISTRIBUTION SYSTEM REAR COMPT) REAR WINDOW ANTENNA (COUPE) RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRY WIRE RED/VIO WIRE RED/WHT WIRE RELAY ENERGIZED RIGHT FRONT MID-RANGE SPEAKER RIGHT FRONT TWEETER RIGHT REAR HI-RANGE SPEAKER RIGHT SIDE TRIM PANEL MID-RANGE SPEAKER RIGHT SUBWOOFER VIO WIRE W/ AUTOMATIC START/STOP FUNCTION W/O AUTOMATIC START/STOP FUNCTION WHT WIRE YEL/BLK WIRE YEL/BRN WIRE YEL/RED WIRE

Go to component: -> Hifi radio circuit, with ccc & m-ask (3 of 3) -> W/ AUTOMATIC START/STOP FUNCTION W/O AUTOMATIC START/STOP FUNCTION

Wiring diagram w/ automatic start/stop function w/o automatic start/stop function (2 of 6)

Wiring diagram w/ automatic start/stop function w/o automatic start/stop function for BMW 1 series F20/F21 (2011-2015)

Get access

AUX-IN CONNECTION BLK WIRE BLU WIRE BLU/BLK WIRE BLU/RED WIRE BRN WIRE BRN/ORG WIRE CD CHANGER (LEFT SIDE OF COMPUTER DATA LINES SYSTEM CONTROLLER COUPE FUSE 14 FUSE 18 FUSE 19 FUSE 27 GRN WIRE GRY/RED WIRE HOT AT ALL TIMES JUNCTION BOX (UNDER RIGHT SIDE OF DASH) LEFT MICROPHONE MOST DATA BUS CIRCUIT NCA WIRE ORG/GRN WIRE POWER DISTRIBUTION SYSTEM RADIO REAR COMPT) RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/VIO WIRE RELAY ENERGIZED ROOF ANTENNA SATELLITE RECEIVER (LEFT SIDE OF REAR COMPT) SDARS ANTENNA (CONVERTIBLE) VIO WIRE W/ ANTENNA DIVERSITY W/ AUTOMATIC START/STOP FUNCTION W/O AUTOMATIC START/STOP FUNCTION W/O ANTENNA DIVERSITY W/O SATELLITE SATELLITE RECEIVER RECEIVER W/O W/ SATELLITE SATELLITE RECEIVER RECEIVER WHT WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/RED WIRE

Go to component: -> Hifi radio circuit, without cic, ccc & m-ask (1 of 2) -> W/ AUTOMATIC START/STOP FUNCTION W/O AUTOMATIC START/STOP FUNCTION

Wiring diagram w/ automatic start/stop function w/o automatic start/stop function (3 of 6)

Wiring diagram w/ automatic start/stop function w/o automatic start/stop function for BMW 1 series F20/F21 (2011-2015)

Get access

AMPLIFIER (LEFT SIDE OF REAR COMPT) ANTENNA ANTENNA DIVERSITY (IF EQUIPPED) BLK WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE BRN/ORG WIRE BRN/WHT WIRE BRN/YEL WIRE CONVERTIBLE COUPE FM ANTENNA 2 (CONVERTIBLE) FM ANTENNA 3 (CONVERTIBLE) FUSE 15 GRY WIRE HOT AT ALL TIMES JUNCTION BOX (UNDER RIGHT SIDE OF DASH) LEFT FRONT MID-RANGE SPEAKER LEFT FRONT TWEETER LEFT REAR HI-RANGE SPEAKER LEFT SIDE TRIM PANEL LEFT SUBWOOFER MID-RANGE SPEAKER NCA WIRE REAR WINDOW AERIAL (COUPE) RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRY WIRE RED/WHT WIRE RELAY ENERGIZED RIGHT FRONT MID-RANGE SPEAKER RIGHT FRONT TWEETER RIGHT REAR HI-RANGE SPEAKER RIGHT SIDE TRIM PANEL MID-RANGE SPEAKER RIGHT SUBWOOFER W/ AUTOMATIC START/STOP FUNCTION W/O AUTOMATIC START/STOP FUNCTION WHT WIRE YEL/BLK WIRE YEL/BRN WIRE YEL/RED WIRE

Go to component: -> Hifi radio circuit, without cic, ccc & m-ask (2 of 2) -> W/ AUTOMATIC START/STOP FUNCTION W/O AUTOMATIC START/STOP FUNCTION

Wiring diagram w/ automatic start/stop function w/o automatic start/stop function (4 of 6)

Wiring diagram w/ automatic start/stop function w/o automatic start/stop function for BMW 1 series F20/F21 (2011-2015)

Get access

AMPLIFIER (LEFT SIDE OF ANTENNA DIVERSITY (IF EQUIPPED) BLK WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE BRN/ORG WIRE BRN/WHT WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM CONTROLLER COUPE CONVERTIBLE DASH) FM ANTENNA 2 ANTENNA (CONVERTIBLE) (CONVERTIBLE) FM ANTENNA 3 (CONVERTIBLE) FUSE FUSE 15 GRN WIRE GRY WIRE HOT AT ALL TIMES JUNCTION BOX (UNDER RIGHT SIDE OF LEFT FRONT MID-RANGE SPEAKER LEFT FRONT TWEETER LEFT REAR HI-RANGE SPEAKER LEFT SIDE TRIM PANEL MID-RANGE SPEAKER LEFT SUBWOOFER NCA WIRE ORG/GRN WIRE POWER DISTRIBUTION SYSTEM REAR COMPT) REAR WINDOW ANTENNA (COUPE) RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRY WIRE RED/VIO WIRE RED/WHT WIRE RELAY ENERGIZED RIGHT FRONT MID-RANGE SPEAKER RIGHT FRONT TWEETER RIGHT REAR HI-RANGE SPEAKER RIGHT SIDE TRIM PANEL MID-RANGE SPEAKER RIGHT SUBWOOFER VIO WIRE W/ AUTOMATIC START/STOP FUNCTION W/O AUTOMATIC START/STOP FUNCTION WHT WIRE YEL/BLK WIRE YEL/BRN WIRE YEL/RED WIRE

Go to component: -> Navigation circuit, hifi radio with ccc & m-ask (3 of 3) -> W/ AUTOMATIC START/STOP FUNCTION W/O AUTOMATIC START/STOP FUNCTION

Wiring diagram w/ automatic start/stop function w/o automatic start/stop function (5 of 6)

Wiring diagram w/ automatic start/stop function w/o automatic start/stop function for BMW 1 series F20/F21 (2011-2015)

Get access

AMPLIFIER (LEFT SIDE OF REAR COMPT) BLU/BLK WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/WHT WIRE BRN WIRE BRN/WHT WIRE BRN/YEL WIRE FUSE 15 GRN WIRE HOT AT ALL TIMES JUNCTION BOX (UNDER RIGHT SIDE OF DASH) LEFT FRONT MID-RANGE SPEAKER LEFT FRONT TWEETER LEFT REAR HI-RANGE SPEAKER LEFT REAR MID-RANGE SPEAKER LEFT SUBWOOFER MOST DATA BUS CIRCUIT RED/BLU WIRE RED/GRY WIRE RED/WHT WIRE RELAY ENERGIZED RIGHT FRONT MID-RANGE SPEAKER RIGHT FRONT TWEETER RIGHT REAR HI-RANGE SPEAKER RIGHT REAR MID-RANGE SPEAKER RIGHT SUBWOOFER W/ AUTOMATIC START/STOP FUNCTION W/O AUTOMATIC START/STOP FUNCTION YEL/BRN WIRE YEL/RED WIRE

Go to component: -> Navigation circuit, top hifi radio -> W/ AUTOMATIC START/STOP FUNCTION W/O AUTOMATIC START/STOP FUNCTION

Wiring diagram w/ automatic start/stop function w/o automatic start/stop function (6 of 6)

Wiring diagram w/ automatic start/stop function w/o automatic start/stop function for BMW 1 series F20/F21 (2011-2015)

Get access

AMPLIFIER (LEFT SIDE OF REAR COMPT) BLU/BLK WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/WHT WIRE BRN WIRE BRN/WHT WIRE BRN/YEL WIRE FUSE 15 GRN WIRE HOT AT ALL TIMES JUNCTION BOX (UNDER RIGHT SIDE OF DASH) LEFT FRONT MID-RANGE SPEAKER LEFT FRONT TWEETER LEFT REAR HI-RANGE SPEAKER LEFT REAR MID-RANGE SPEAKER LEFT SUBWOOFER MOST DATA BUS CIRCUIT RED/BLU WIRE RED/GRY WIRE RED/WHT WIRE RELAY ENERGIZED RIGHT FRONT MID-RANGE SPEAKER RIGHT FRONT TWEETER RIGHT REAR HI-RANGE SPEAKER RIGHT REAR MID-RANGE SPEAKER RIGHT SUBWOOFER W/ AUTOMATIC START/STOP FUNCTION W/O AUTOMATIC START/STOP FUNCTION YEL/BRN WIRE YEL/RED WIRE

Go to component: -> Top hifi radio circuit -> W/ AUTOMATIC START/STOP FUNCTION W/O AUTOMATIC START/STOP FUNCTION
