BMW 1 series F20/F21 (2011-2015) terminal 30 rf whl spd rf whl spd Wiring diagram

ACTIVE STEERING (BEHIND LEFT FRONT WHEEL) BLK/RED/WHT WIRE BLK/VIO WIRE BLK/YEL WIRE BLU WIRE BLU/ WHT WIRE BLU/BRN/YEL WIRE BLU/RED WIRE BLU/VIO WIRE BLU/WHT/YEL WIRE BRAKE FLUID LEVEL SWITCH (LEFT REAR OF ENGINE COMPT) BRAKE LIGHT SWITCH (UNDER LEFT SIDE OF DASH) BRK FLD LVL BRK LIGHT LF BRK PAD BRN WIRE BRN/BLK WIRE BRN/GRN/YEL WIRE BRN/RED WIRE CAR ACCESS SYSTEM (UNDER LEFT SIDE OF DASH) COMPUTER DATA LINES SYSTEM COND WHL SPD F-CAN-LOW DSC SENS DME CONTROL MODULE (RIGHT REAR OF ENGINE COMPT) DSC SENSOR (UNDER DRIVER'S SEAT) DSC SENSOR 2 DYNAMIC STABILITY CONTROL (DSC) (LEFT REAR OF ENGINE COMPT) ELECTRONICS JUNCTION BOX F-CAN HIGH RF WHL OUT FUSE GRN/RED WIRE HAZARD WARNING SWITCH HOT AT ALL TIMES HOT W/ TERMINAL JUNCTION BOX (UNDER RIGHT SIDE OF DASH) LEFT FRONT WHEEL SPEED SENSOR (FRONT OF LEFT FRONT WHEEL) LEFT REAR WHEEL SPEED SENSOR (BEHIND LEFT REAR WHEEL) LF WHL OUT PT CAN LOW GROUND LF WHL SPD LF WHL SPD GROUND LR WHL SPD LR WHL SPD PARKING BRK DSC SENS RR BRK PAD NCA WIRE PARKING BRAKE WARNING SWITCH (UNDER CENTER CONSOLE) RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRY WIRE RED/YEL WIRE RIGHT FRONT WHEEL SPEED SENSOR (FRONT OF RIGHT FRONT WHEEL) RIGHT REAR WHEEL SPEED SENSOR (BEHIND RIGHT REAR WHEEL) RR BRK PAD RR WHL OUT RF BRK PAD RR WHL SPD RR WHL SPD STEERING COLUMN SWITCH CLUSTER TELEPHONE TRANSCEIVER (CENTER OF REAR COMPT) TERMINAL 30 RF WHL SPD RF WHL SPD VIO WIRE VIO/WHT WIRE W/ NAVIGATION (NOT USED) W/O NAVIGATION WAKE UP PT CAN HIGH WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/YEL WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/BRN WIRE YEL/RED WIRE YEL/VIO WIRE YEL/WHT WIRE
