BMW 1 series F20/F21 (2011-2015) right front electronic wheel module (on right Wiring diagram
This page shows the only wiring diagram for the component.right front electronic wheel module (on right, which is found in the car BMW 1 series F20/F21 (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right front electronic wheel module (on right (1 of 1)
BLK/BLU WIRE
BLK/GRN WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BRN WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/WHT WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
FRONT WHEEL)
FUSE 27
GRN WIRE
GRY/BLU WIRE
GRY/GRN WIRE
GRY/WHT WIRE
GRY/YEL WIRE
JUNCTION BOX (UNDER RIGHT SIDE OF DASH)
LEFT FRONT ELECTRONIC WHEEL MODULE (ON LEFT
LEFT FRONT RDC TRANSMITTER (FRONT OF LEFT FRONT WHEELWELL)
LEFT REAR ELECTRONIC WHEEL MODULE (ON LEFT
LEFT REAR RDC TRANSMITTER (REAR OF LEFT REAR WHEELWELL)
ORG/GRN WIRE
POWER DISTRIBUTION SYSTEM
RDC ANTENNA (UNDER VEHICLE)
REAR WHEEL)
RED WIRE
RED/VIO WIRE
RELAY ENERGIZED
RIGHT FRONT ELECTRONIC WHEEL MODULE (ON RIGHT
RIGHT FRONT RDC TRANSMITTER (FRONT OF RIGHT FRONT WHEELWELL)
RIGHT REAR ELECTRONIC WHEEL MODULE (ON RIGHT
RIGHT REAR RDC TRANSMITTER (REAR OF RIGHT REAR WHEELWELL)
TIRE PRESSURE CONTROL (RDC) (RIGHT SIDE OF REAR COMPT)
VIO WIRE
Go to component: -> Warning systems circuit -> RIGHT FRONT ELECTRONIC WHEEL MODULE (ON RIGHT
