BMW 1 series F20/F21 (2011-2015) rear lid sig lid contact can bus can bus rmte cntrl sig Wiring diagrams

This page contains all the electrical diagrams for the component. rear lid sig lid contact can bus can bus rmte cntrl sig, in which he is found in the car BMW 1 series F20/F21 (2011-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram rear lid sig lid contact can bus can bus rmte cntrl sig (1 of 2)

Wiring diagram rear lid sig lid contact can bus can bus rmte cntrl sig for BMW 1 series F20/F21 (2011-2015)

Get access

13 24 42 46 DR CONTACT SIG 29 40 39 38 35 26 33 CENTER SIG AERIAL DIVERSITY (BOTTOM CENTER OF REAR WINDOW) BLK WIRE BLK/BLU WIRE BLU WIRE BLU/RED WIRE BRN WIRE BRN/BLK WIRE BRN/GRY/WHT WIRE BRN/GRY/YEL WIRE BRN/WHT WIRE CAR ACCESS SYSTEM (UNDER LEFT SIDE OF DASH) COMPUTER DATA LINES SYSTEM COUPE DRIVER'S DOOR SYSTEM LOCK (LEFT FRONT DOOR) ELECTROCHROMIC INTERIOR REAR VIEW MIRROR FBD RECEIVER FOOTWELL MODULE (UNDER LEFT SIDE OF DASH) FUSE GRN WIRE GRY/BRN WIRE GRY/GRN WIRE GRY/RED WIRE GRY/YEL WIRE HAZARD WARNING SWITCH HOOD CONTACT SWITCH (LEFT REAR OF ENGINE COMPT) HOT AT ALL TIMES HOTEL SWITCH JUNCTION BOX (UNDER RIGHT SIDE OF DASH) JUNCTION BOX ELECTRONICS LOCKING LOCK SIG UNLOCKING LCK SIG 45 46 K-BUS SIG K-BUS SIG ORG/GRN WIRE REAR LID SIG LID CONTACT CAN BUS CAN BUS RMTE CNTRL SIG REMOTE CONTROL RECEIVER TRUNK LID BUTTON VIO/GRN WIRE WHT WIRE WHT/BLK WIRE YEL/BLU WIRE YEL/BRN WIRE YEL/RED WIRE

Go to component: -> Anti-theft circuit (1 of 3) -> REAR LID SIG LID CONTACT CAN BUS CAN BUS RMTE CNTRL SIG

Wiring diagram rear lid sig lid contact can bus can bus rmte cntrl sig (2 of 2)

Wiring diagram rear lid sig lid contact can bus can bus rmte cntrl sig for BMW 1 series F20/F21 (2011-2015)

Get access

13 24 42 46 DR CONTACT SIG 29 40 39 38 35 26 33 CENTER SIG AERIAL DIVERSITY (BOTTOM CENTER OF REAR WINDOW) BLK WIRE BLK/BLU WIRE BLU WIRE BLU/RED WIRE BRN WIRE BRN/BLK WIRE BRN/GRY/WHT WIRE BRN/GRY/YEL WIRE BRN/WHT WIRE CAR ACCESS SYSTEM (UNDER LEFT SIDE OF DASH) COMPUTER DATA LINES SYSTEM COUPE DRIVER'S DOOR SYSTEM LOCK (LEFT FRONT DOOR) ELECTROCHROMIC INTERIOR REAR VIEW MIRROR FBD RECEIVER FOOTWELL MODULE (UNDER LEFT SIDE OF DASH) FUSE GRN WIRE GRY/BRN WIRE GRY/GRN WIRE GRY/RED WIRE GRY/YEL WIRE HAZARD WARNING SWITCH HOOD CONTACT SWITCH (LEFT REAR OF ENGINE COMPT) HOT AT ALL TIMES HOTEL SWITCH JUNCTION BOX (UNDER RIGHT SIDE OF DASH) JUNCTION BOX ELECTRONICS LOCKING LOCK SIG UNLOCKING LCK SIG 45 46 K-BUS SIG K-BUS SIG ORG/GRN WIRE REAR LID SIG LID CONTACT CAN BUS CAN BUS RMTE CNTRL SIG REMOTE CONTROL RECEIVER TRUNK LID BUTTON VIO/GRN WIRE WHT WIRE WHT/BLK WIRE YEL/BLU WIRE YEL/BRN WIRE YEL/RED WIRE

Go to component: -> Power door locks circuit (1 of 3) -> REAR LID SIG LID CONTACT CAN BUS CAN BUS RMTE CNTRL SIG
