BMW 1 series F20/F21 (2011-2015) luggage well b+ terminal point Wiring diagrams

ALTERNATOR BATTERY BATTERY SENSOR (RIGHT SIDE OF REAR COMPT) BRN WIRE COMPUTER DATA LINES SYSTEM FUSE GRN/RED WIRE GRY WIRE JUMP START TERMINAL POINT (RIGHT SIDE OF ENGINE COMPT) LUGGAGE WELL B+ TERMINAL POINT N/A NCA WIRE REAR FUSE HOLDER (RIGHT SIDE OF REAR COMPT) RED WIRE STARTER VIO WIRE

ALTERNATOR BATTERY BATTERY SENSOR (RIGHT SIDE OF REAR COMPT) BLU WIRE BRN WIRE CAR ACCESS SYSTEM COMPUTER DATA LINES SYSTEM CONVERTIBLE TOP RELAY 1 CONVERTIBLE TOP RELAY 2 DME CONTROL MODULE DME RELAY DRIVER'S SEAT HEATING MODULE ELECTRIC COOLANT PUMP ELECTRONIC POWER STEERING (EPS) ENGINE CONTROLS FUSE CARRIER (RIGHT PLENUM CHAMBER E-BOX) FOOTWELL MODULE FUSE FUSE 106 FUSE 4 GRN WIRE GRY WIRE HEADLIGHT WASHER RELAY HOLDER (RIGHT SIDE OF REAR COMPT) FUSE 101 IGNITION, FUEL INJECTION RELAY (3.0L TWIN TURBO) JUMP START TERMINAL POINT (RIGHT SIDE OF ENGINE COMPT) JUNCTION BOX (UNDER RIGHT SIDE OF DASH) LUGGAGE WELL B+ TERMINAL POINT N/A NCA WIRE PASSENGER'S SEAT HEATING MODULE REAR FUSE REAR WINDOW WIPER RELAY RED WIRE RED/BLK WIRE RED/GRN WIRE RED/VIO WIRE RED/WHT WIRE ROOF FUNCTION CONTROL CENTER STARTER TO FUSE 67 (DIAGRAM 2 OF 5) VALVETRONIC RELAY VIO WIRE WHT WIRE

A/T BATTERY BLK WIRE BLK/GRN WIRE BLU WIRE BLU/BLK WIRE BRN WIRE CAR ACCESS SYSTEM (UNDER LEFT SIDE OF DASH) CHARGING CIRCUIT CLUTCH SWITCH MODULE (UNDER LEFT SIDE OF DASH) DME CONTROL MODULE DYNAMIC STABILITY CONTROL (LEFT REAR OF ENGINE COMPT) GRY WIRE JUMP LUGGAGE WELL B+ TERMINAL POINT M/T NCA WIRE RED WIRE SIDE-IN COMPARTMENT START-STOP BUTTON STARTER TERMINAL POINT (RIGHT SIDE OF ENGINE COMPT) TRANSMISSION CONTROL WHT WIRE YEL WIRE YEL/RED WIRE
