BMW 1 series F20/F21 (2011-2015) fuse side of dash) Wiring diagram

This page shows the only wiring diagram for the component.fuse side of dash), which is found in the car BMW 1 series F20/F21 (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram fuse side of dash) (1 of 1)

Wiring diagram fuse side of dash) for BMW 1 series F20/F21 (2011-2015)

Get access

BLK WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/YEL WIRE BRN WIRE ELECTRONIC STEERING WHEEL MODULE ELECTRONICS JUNCTION BOX FUSE SIDE OF DASH) GRN WIRE GRN/RED WIRE HOT W/ TERMINAL 15 RELAY ENERGIZED JUNCTION BOX (UNDER RIGHT RED WIRE STEERING COLUMN SWITCH CLUSTER STEERING WHEEL HEATER SWITCH STEERING WHEEL HEATING W/ TEMPERATURE SENSOR WHT WIRE
