BMW 1 series F20/F21 (2011-2015) convertible top relay 2 Wiring diagram
This page shows the only wiring diagram for the component.convertible top relay 2, which is found in the car BMW 1 series F20/F21 (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram convertible top relay 2 (1 of 1)
ALTERNATOR
BATTERY
BATTERY SENSOR (RIGHT SIDE OF REAR COMPT)
BLU WIRE
BRN WIRE
CAR ACCESS SYSTEM
COMPUTER DATA LINES SYSTEM
CONVERTIBLE TOP RELAY 1
CONVERTIBLE TOP RELAY 2
DME CONTROL MODULE
DME RELAY
DRIVER'S SEAT HEATING MODULE
ELECTRIC COOLANT PUMP
ELECTRONIC POWER STEERING (EPS)
ENGINE CONTROLS FUSE CARRIER (RIGHT PLENUM CHAMBER E-BOX)
FOOTWELL MODULE
FUSE
FUSE 106
FUSE 4
GRN WIRE
GRY WIRE
HEADLIGHT WASHER RELAY
HOLDER (RIGHT SIDE OF REAR COMPT) FUSE 101
IGNITION, FUEL INJECTION RELAY (3.0L TWIN TURBO)
JUMP START TERMINAL POINT (RIGHT SIDE OF ENGINE COMPT)
JUNCTION BOX (UNDER RIGHT SIDE OF DASH)
LUGGAGE WELL B+ TERMINAL POINT
N/A
NCA WIRE
PASSENGER'S SEAT HEATING MODULE
REAR FUSE
REAR WINDOW WIPER RELAY
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
RED/VIO WIRE
RED/WHT WIRE
ROOF FUNCTION CONTROL CENTER
STARTER
TO FUSE 67 (DIAGRAM 2 OF 5)
VALVETRONIC RELAY
VIO WIRE
WHT WIRE
Go to component: -> Power distribution circuit (1 of 5) -> CONVERTIBLE TOP RELAY 2
