BMW 1 series F20/F21 (2011-2015) convertible top compartment lid locked switch Wiring diagram
This page shows the only wiring diagram for the component.convertible top compartment lid locked switch, which is found in the car BMW 1 series F20/F21 (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram convertible top compartment lid locked switch (1 of 1)
BLK/GRN WIRE
BLK/RED WIRE
BRN WIRE
CAR ACCESS SYSTEM (UNDER LEFT SIDE OF DASH)
CLAMPING BRACKET ERECTED HALL SENSOR
CLAMPING BRACKET TAKEN DOWN HALL SENSOR
CONVERTIBLE TOP COMPARTMENT FLOOR SWITCH (LEFT FRONT OF REAR COMPT)
CONVERTIBLE TOP COMPARTMENT LID LOCKED SWITCH
COWL PANEL LOCKED HALL SENSOR
GRN/WHT WIRE
LOCKING COWL PANEL DRIVE (CENTER FRONT OF ROOF)
MAIN PILLAR ERECTED HALL SENSOR
MAIN PILLAR TAKEN DOWN HALL SENSOR
NCA WIRE
RED WIRE
TENSIONING BAR EXTENDED HALL SENSOR
WHT/BRN WIRE
WHT/YEL WIRE
WIND SCREEN COWL PANEL LATCH INCREMENTAL TRANSDUCER DRIVE UNIT
YEL WIRE
YEL/BLU WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component: -> Convertible top circuit (2 of 2) -> CONVERTIBLE TOP COMPARTMENT LID LOCKED SWITCH
