BMW 1 series F20/F21 (2011-2015) cd changer (left side of Wiring diagram
This page shows the only wiring diagram for the component.cd changer (left side of, which is found in the car BMW 1 series F20/F21 (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram cd changer (left side of (1 of 1)
AUX-IN CONNECTION
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BRN WIRE
BRN/ORG WIRE
CD CHANGER (LEFT SIDE OF
COMPUTER DATA LINES SYSTEM
CONTROLLER
COUPE
FUSE 14
FUSE 18
FUSE 19
FUSE 27
GRN WIRE
GRY/RED WIRE
HOT AT ALL TIMES
JUNCTION BOX (UNDER RIGHT SIDE OF DASH)
LEFT MICROPHONE
MOST DATA BUS CIRCUIT
NCA WIRE
ORG/GRN WIRE
POWER DISTRIBUTION SYSTEM
RADIO
REAR COMPT)
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/VIO WIRE
RELAY ENERGIZED
ROOF ANTENNA
SATELLITE RECEIVER (LEFT SIDE OF REAR COMPT)
SDARS ANTENNA (CONVERTIBLE)
VIO WIRE
W/ ANTENNA DIVERSITY
W/ AUTOMATIC START/STOP FUNCTION W/O AUTOMATIC START/STOP FUNCTION
W/O ANTENNA DIVERSITY
W/O SATELLITE SATELLITE RECEIVER RECEIVER
W/O W/ SATELLITE SATELLITE RECEIVER RECEIVER
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLK WIRE
YEL/RED WIRE
Go to component: -> Hifi radio circuit, without cic, ccc & m-ask (1 of 2) -> CD CHANGER (LEFT SIDE OF
