BMW 1 series F20/F21 (2011-2015) base plate Wiring diagram
This page shows the only wiring diagram for the component.base plate, which is found in the car BMW 1 series F20/F21 (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram base plate (1 of 1)
AUC SENSOR
AUXILIARY
AUXILIARY BRAKE LIGHT
BASE PLATE
BRAKE LIGHT
BRN WIRE
BRN/BLK WIRE
CD CHANGER
COMBOX
COUPE
DIGITAL TUNER US
DIODE (EKPS) PANEL
EJECT BOX
ELECTRO- CHROMIC INTERIOR REAR-VIEW MIRROR
ELECTRONICS JUNCTION BOX
FOOTWELL MODULE
FUEL PUMP CONTROL
GEAR INDICATOR LIGHTING
NCA WIRE
PARK DISTANCE CONTROL (PDC)
PASSENGER'S PASSENGER'S REAR SIDE REAR SIDE POWER SYSTEM WINDOW LOCK SWITCH
PASSENGER'S REAR SIDE ENTRANCE LIGHT
RIGHT HEAD- LIGHT
SATELLITE RECEIVER
STEPTRONIC SWITCH
TELEPHONE TCU RETROFIT PACKAGES CONNECTOR
TELEPHONE TRANSCEIVER
TRAILER MODULE
TRAILER SOCKET
TRUNK LID BUTTON
ULF
ULF- SBX-H
ULF-SBX
USB AMPLIFIER HUB
VIDEO MODULE
W/ XENON HEAD- LIGHT
W/ XENON HEADLIGHT
WASHER FLUID LEVEL SWITCH
