BMW 1 series F20/F21 (2011-2015) 7 8 20 can low can hi activation Wiring diagrams

This page contains all the electrical diagrams for the component. 7 8 20 can low can hi activation, in which he is found in the car BMW 1 series F20/F21 (2011-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram 7 8 20 can low can hi activation (1 of 2)

Wiring diagram 7 8 20 can low can hi activation for BMW 1 series F20/F21 (2011-2015)

Get access

41 13 15 55 SENS GND SIG 7 8 20 CAN LOW CAN HI ACTIVATION ACTIVATION AIR DISTRIBUTION FLAP MOTOR (ON HVAC UNIT) BLK/BLU WIRE BLK/VIO WIRE BLU WIRE BLU/RED WIRE BRN WIRE CHARACTERISTIC MAP THERMOSTAT (REAR OF ENGINE) COMPUTER DATA LINES SYSTEM DEFROSTER FLAP MOTOR (ON HVAC UNIT) DME CONTROL MODULE (RIGHT REAR OF ELECTRIC COOLANT PUMP (REAR OF ENGINE) ELECTRIC FAN (FRONT OF ENGINE COMPT) ELECTRIC FAN CUT OUT RELAY ENGINE COMPT) ENGINE COOLANT TEMPERATURE SENSOR FOOTWELL FLAP MOTOR (ON HVAC UNIT) FRESH AIR/RECIRCULATED AIR FLAP MOTOR (ON HVAC UNIT) FUSE GRN WIRE HOT AT ALL TIMES HOT W/ TERMINAL JUNCTION BOX (UNDER RIGHT SIDE OF DASH) LEFT MIXED AIR FLAP MOTOR (ON HVAC UNIT) MIXER FLAP MOTOR (ON HVAC UNIT) ORG/ WIRE RED WIRE RED/BLU WIRE RED/GRN WIRE RIGHT MIXED AIR FLAP MOTOR (ON HVAC UNIT) SENS SIG VENTILATION FLAP MOTOR (ON HVAC UNIT) VIO WIRE WHT WIRE YEL/RED WIRE

Go to component: -> Automatic a/c circuit (2 of 2) -> 7 8 20 CAN LOW CAN HI ACTIVATION

Wiring diagram 7 8 20 can low can hi activation (2 of 2)

Wiring diagram 7 8 20 can low can hi activation for BMW 1 series F20/F21 (2011-2015)

Get access

41 13 15 55 SENS GND SIG 7 8 20 CAN LOW CAN HI ACTIVATION ACTIVATION BLK/BLU WIRE BLK/VIO WIRE BLU/RED WIRE BRN WIRE CHARACTERISTIC MAP THERMOSTAT (REAR OF ENGINE) COMPUTER DATA LINES SYSTEM DME CONTROL MODULE (RIGHT REAR OF ELECTRIC COOLANT PUMP (REAR OF ENGINE) ELECTRIC FAN (FRONT OF ENGINE COMPT) ELECTRIC FAN CUT OUT RELAY ENGINE COMPT) ENGINE COOLANT TEMPERATURE SENSOR FUSE FUSE RIGHT SIDE OF DASH) HOT AT ALL TIMES HOT W/ TERMINAL JUNCTION BOX (UNDER ORG/ WIRE RED WIRE RED/BLU WIRE RED/GRN WIRE SENS SIG VIO WIRE WHT WIRE YEL/RED WIRE

Go to component: -> Cooling fan circuit -> 7 8 20 CAN LOW CAN HI ACTIVATION
