BMW 1 series F20/F21 (2011-2015) 1 2 3 4 5 6 steering sig steering sig steering sig Wiring diagram

1 2 3 4 5 6 STEERING SIG STEERING SIG STEERING SIG ACTIVE STEERING (BEHIND LEFT FRONT WHEEL) BLK WIRE BLK/BRN WIRE BLK/RED WIRE BLK/WHT WIRE BLU WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/BLK WIRE CAN-BUS CAN-BUS COMPUTER DATA LINES SYSTEM ECO VALVE (UNDER STARTER) ECO VLV SIG SOL VLV ELECTRIC LOCK (ON STEERING MOTOR ASSEMBLY) FUSE 49 SIDE OF DASH) JUNCTION BOX (UNDER RIGHT NCA WIRE RED WIRE RED/BRN WIRE RED/GRN WIRE RELAY ENERGIZED STEERING GEAR (ON STEERING RACK ASSEMBLY) SUPPLY STEERING GND VIO/GRN WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE WHT/YEL WIRE YEL WIRE YEL/BRN WIRE
