Radio circuit, except convertible with car information computer, base radio for BMW 1 series E81/E82/E87/E88 facelift (2007-2011)

ANTENNA DIVERSITY BISTABLE RELAY BLK WIRE BLU WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE CAR INFORMATION COMPUTER CIC CENTRAL INFORMATION DISPLAY COMPUTER DATA LINES SYSTEM ELECTRONICS JUNCTION BOX FUSE GRN WIRE GRY/RED WIRE HOT AT ALL TIMES JUNCTION BOX (UNDER RIGHT SIDE OF DASH) NCA WIRE OBDII SOCKET ORG/ WIRE ORG/GRN WIRE REAR-WINDOW AERIAL RED WIRE RED/GRN WIRE RED/YEL WIRE USB PORT WHT WIRE YEL WIRE YEL/BRN WIRE YEL/RED WIRE

BLK WIRE BLU WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/WHT WIRE BRN WIRE CD CHANGER (LEFT SIDE OF REAR COMPT) DIGITAL TUNER US (DAB) FUSE 18 FUSE 19 GRN WIRE JUNCTION BOX (UNDER RIGHT SIDE OF DASH) LEFT FRONT MID-RANGE SPEAKER LEFT REAR MID- RANGE SPEAKER LEFT SUB- WOOFER MOST-BUS CONNECTOR RED WIRE RED/BLK WIRE RED/BLU WIRE RELAY ENERGIZED RIGHT FRONT MID-RANGE SPEAKER RIGHT REAR MID-RANGE SPEAKER RIGHT SUB- WOOFER ROOF ANTENNA SAT SATELLITE RECEIVER (LEFT SIDE OF REAR COMPT) TELEPHONE TRANSCEIVER WHT WIRE YEL/BRN WIRE YEL/RED WIRE
