Car Wiring Diagrams for Radio circuit, convertible with base radio for BMW 1 series E81/E82/E87/E88 facelift (2007-2011)

ANTENNA DIVERSITY AV SOCKET BLK WIRE BLK/BLU WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/WHT WIRE BRN WIRE CD CHANGER (LEFT SIDE OF REAR COMPT) COMPUTER DATA LINES SYSTEM CONVERTIBLE TOP MODULE FM ANTENNA 1 FM ANTENNA 3 FM FM ANTENNA 2 ANTENNA 4 FUSE 14 FUSE 18 FUSE 19 GRN WIRE GRY WIRE GRY/RED WIRE JUNCTION BOX (UNDER RIGHT SIDE OF DASH) LEFT FRONT MID-RANGE SPEAKER LEFT REAR MID-RANGE SPEAKER LEFT SIDE SECTION ANTENNA AMPLIFIER LEFT SUB- WOOFER MOST-BUS CONNECTOR NCA WIRE ORG/GRN WIRE RADIO REAR WINDOW ANTENNA AMPLIFIER REAR-WINDOW AERIAL RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RELAY ENERGIZED RIGHT FRONT MID-RANGE SPEAKER RIGHT REAR MID-RANGE SPEAKER RIGHT SIDE SECTION ANTENNA AMPLIFIER RIGHT SUB- WOOFER ROOF ANTENNA 2 SAT SATELLITE RECEIVER (LEFT SIDE OF REAR COMPT) TCU TELEPHONE RETROFIT PACKAGES CONNECTOR TELEPHONE TRANSCEIVER (CENTER OF REAR COMPT) WHT WIRE WHT/BRN WIRE YEL/BRN WIRE YEL/RED WIRE
