Navigation circuit, convertible without car information computer, top hifi radio for BMW 1 series E81/E82/E87/E88 facelift (2007-2011)

1 2 3 4 (PIN 5-10 NOT USED) BISTABLE RELAY BLK WIRE BLU WIRE BRN WIRE CCC/M-ASK CD CHANGER (LEFT SIDE OF REAR COMPT) CENTRAL INFORMATION DISPLAY COMPUTER DATA LINES SYSTEM DIGITAL TUNER US (DAB) ELECTRONICS JUCNTION BOX FUSE FUSE 18 FUSE 19 GRN WIRE GRY WIRE GRY/RED WIRE HOT AT ALL TIMES JUNCTION BOX (UNDER RIGHT SIDE OF DASH) MOST-BUS CONNECTOR NCA WIRE ON LEFT IN BUMPER TV ANTENNA ON RIGHT IN BUMPER TV ANTENNA ORG/ WIRE ORG/GRN WIRE RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/YEL WIRE ROOF ANTENNA ROOF ANTENNA 2 SAT SATELLITE RECEIVER (LEFT SIDE OF REAR COMPT) TCU 1 2 VIDEO MODULE (LEFT SIDE OF REAR COMPT) WHT WIRE YEL WIRE

AMPLIFIER (LEFT SIDE OF REAR COMPT) ANTENNA DIVERSITY BLK WIRE BLK/BLU WIRE BLK/BRN WIRE BLK/WHT WIRE BLK/YEL WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/WHT WIRE BRN WIRE BRN/GRN WIRE BRN/WHT WIRE BRN/YEL WIRE CENTER SPEAKER CONVERTIBLE TOP MODULE FM ANTENNA 1 FM ANTENNA 2 FM ANTENNA 3 FM ANTENNA 4 FUSE 15 GRN WIRE GRY WIRE JUNCTION BOX (UNDER RIGHT SIDE OF DASH) LEFT FRONT MID-RANGE SPEAKER LEFT FRONT TWEETER LEFT REAR HI-RANGE SPEAKER LEFT REAR MID-RANGE SPEAKER LEFT SIDE SECTION ANTENNA AMPLIFIER LEFT SIDE TRIM PANEL MID-RANGE SPEAKER LEFT SUBWOOFER NCA WIRE REAR WINDOW ANTENNA AMPLIFIER REAR-WINDOW AERIAL RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRY WIRE RED/WHT WIRE RELAY ENERGIZED RIGHT FRONT MID-RANGE SPEAKER RIGHT REAR DOOR MID-RANGE SPEAKER RIGHT REAR HI-RANGE SPEAKER RIGHT REAR MID-RANGE SPEAKER RIGHT SIDE SECTION ANTENNA AMPLIFIER RIGHT SUBWOOFER WHT WIRE YEL/BRN WIRE YEL/RED WIRE
