BMW 1 series E81/E82/E87/E88 facelift (2007-2011) passenger's seat backrest width adjustment valve block Wiring diagram
This page shows the only wiring diagram for the component.passenger's seat backrest width adjustment valve block, which is found in the car BMW 1 series E81/E82/E87/E88 facelift (2007-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passenger's seat backrest width adjustment valve block (1 of 1)
AF INTERFERENCE SUPPRESSOR FILTER
BLOWER OUTPUT STAGE
BLU/GRY WIRE
BRN WIRE
ELECTRONICS JUNCTION BOX
FRONT INTERIOR/ READING LAMP
INDEPENDENT/ AUXILIARY HEATING CONTROL MODULE
LEFT FOG LIGHT
LEFT FRONT DIRECTION INDICATOR
LEFT RIGHT HEATED HEATED WASHER WASHER NOZZLE NOZZLE
LEFT TAILLIGHT
NCA WIRE
PASSENGER'S DOOR ENTRANCE LIGHT
PASSENGER'S DOOR POWER WINDOW SWITCH
PASSENGER'S DOOR SYSTEM LOCK
PASSENGER'S LUMBAR SUPPORT SWITCH
PASSENGER'S SEAT ADJUSTMENT SWITCH
PASSENGER'S SEAT BACKREST WIDTH ADJUSTMENT VALVE BLOCK
PASSENGER'S SEAT HEATING MODULE
PASSENGER'S SEAT VACUUM PUMP
PASSENGER'S SIDE FOOTWELL LIGHT
PASSENGER'S SIDE OUTER DOOR HANDLE ELECTRONIC MODULE
PASSENGER'S SIDE OUTSIDE MIRROR
REAR DRIVER'S SIDE DOOR ENTRANCE LIGHT
REAR DRIVER'S SIDE POWER WINDOW SWITCH
REAR DRIVER'S SIDE SYSTEM LOCK
REPEATER LIGHT
ROOF FUNCTION CONTROL CENTER
SIREN, ALARM SENSOR
WIPER MOTOR
Go to component: -> Ground distribution circuit (1 of 4) -> PASSENGER'S SEAT BACKREST WIDTH ADJUSTMENT VALVE BLOCK
