BMW 1 series E81/E82/E87/E88 facelift (2007-2011) nca Wiring diagrams
This page contains all the electrical diagrams for the component. nca, in which he is found in the car BMW 1 series E81/E82/E87/E88 facelift (2007-2011). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram nca (51 of 89)
AIR CONDITIONING SYSTEM
BLK WIRE
BLK/GRN WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLU WIRE
BLU/YEL WIRE
BRN WIRE
BRN/BLK WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/RED WIRE
BRN/VIO WIRE
COMPUTER DATA LINES SYSTEM
CONVERTIBLE TOP DRIVE
CONVERTIBLE TOP DRIVE VALVE 1
CONVERTIBLE TOP DRIVE VALVE 2
CONVERTIBLE TOP DRIVE VALVE 3
CONVERTIBLE TOP LID OPEN HALL SENSOR
CONVERTIBLE TOP MODULE
CONVERTIBLE TOP RELAY 1
CONVERTIBLE TOP RELAY 2
FUSE
FUSE HOLDER (RIGHT SIDE OF REAR COMPT)
GRN WIRE
GRN/BLK WIRE
GRY WIRE
GRY/BLK WIRE
GRY/GRN WIRE
HOT AT ALL TIMES
JUNCTION BOX (UNDER RIGHT SIDE OF DASH)
NCA WIRE
ORG/GRN WIRE
REAR FUSE
RED WIRE
RED/GRY WIRE
RED/WHT WIRE
RELAY ENERGIZED
WHT/BLK WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/YEL WIRE
YEL/BLK WIRE
YEL/BLU WIRE
YEL/BRN WIRE
YEL/GRN WIRE
YEL/RED WIRE
YEL/VIO WIRE
Go to component -> Convertible top circuit (1 of 2) -> NCA WIRE
Wiring diagram nca (52 of 89)
BLK/GRN WIRE
BLK/RED WIRE
BRN WIRE
BRN/BLK WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/VIO WIRE
CAR ACCESS SYSTEM (UNDER LEFT SIDE OF DASH)
CLAMPING BRACKET ERECTED HALL SENSOR
CLAMPING BRACKET TAKEN DOWN HALL SENSOR
CONVERTIBLE TOP COMPARTMENT FLOOR SWITCH
CONVERTIBLE TOP COMPARTMENT LID LOCKED HALL SENSOR
COWL PANEL LOCKED HALL SENSOR
GRN/BLK WIRE
GRY/BLK WIRE
GRY/GRN WIRE
LOCKING COWL PANEL DRIVE
MAIN PILLAR ERECTED HALL SENSOR
MAIN PILLAR TAKEN DOWN HALL SENSOR
NCA WIRE
RED WIRE
TENSIONING BAR EXTENDED HALL SENSOR
TOWING HITCH RELEASE
WHT/BRN WIRE
WHT/YEL WIRE
WIND SCREEN COWL PANEL LATCH INCREMENTAL TRANSDUCER DRIVE UNIT
YEL/BLK WIRE
YEL/BLU WIRE
YEL/BRN WIRE
YEL/GRN WIRE
YEL/RED WIRE
YEL/VIO WIRE
Go to component -> Convertible top circuit (2 of 2) -> NCA WIRE
Wiring diagram nca (53 of 89)
BLU WIRE
BLU/VIO WIRE
BLU/WHT WIRE
BRN WIRE
CENTER CONSOLE SWITCH CENTER
DRIVER'S SEAT BACKREST HEATING (IN DRIVER SEAT BACK)
DRIVER'S SEAT CUSHION HEATING (IN DRIVER SEAT CUSHION)
DRIVER'S SEAT HEATING MODULE (UNDER DRIVER SEAT)
FUSE 10
FUSE 3
FUSE 68
GRN WIRE
GRN/BRN WIRE
HEATING, A/C SYSTEM
HOT AT ALL TIMES
HOT W/ TERMINAL 15 RELAY ENERGIZED
JUNCTION BOX (UNDER RIGHT SIDE OF DASH)
JUNCTION BOX ELECTRONICS
NCA WIRE
PASSENGER'S SEAT BACKREST HEATING (IN PASSENGER SEAT BACK)
PASSENGER'S SEAT CUSHION HEATING
PASSENGER'S SEAT HEATING MODULE (UNDER FRONT PASSENGER'S SEAT)
RED WIRE
RED/VIO WIRE
RED/WHT WIRE
RED/YEL WIRE
RELAY ENERGIZED FUSE 77
VIO WIRE
WHT WIRE
WHT/BLU WIRE
WHT/YEL WIRE
YEL WIRE
Go to component -> Heated seats circuit -> NCA WIRE
Wiring diagram nca (54 of 89)
Go to component -> Power mirrors circuit, without heated mirrors -> NCA WIRE
Wiring diagram nca (55 of 89)
ANTENNA DIVERSITY
AV SOCKET
BLK WIRE
BLK/BLU WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/WHT WIRE
BRN WIRE
CD CHANGER (LEFT SIDE OF REAR COMPT)
COMPUTER DATA LINES SYSTEM
CONVERTIBLE TOP MODULE
FM ANTENNA 1
FM ANTENNA 3
FM FM ANTENNA 2 ANTENNA 4
FUSE 14
FUSE 18
FUSE 19
GRN WIRE
GRY WIRE
GRY/RED WIRE
JUNCTION BOX (UNDER RIGHT SIDE OF DASH)
LEFT FRONT MID-RANGE SPEAKER
LEFT REAR MID-RANGE SPEAKER
LEFT SIDE SECTION ANTENNA AMPLIFIER
LEFT SUB- WOOFER
MOST-BUS CONNECTOR
NCA WIRE
ORG/GRN WIRE
RADIO
REAR WINDOW ANTENNA AMPLIFIER
REAR-WINDOW AERIAL
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RELAY ENERGIZED
RIGHT FRONT MID-RANGE SPEAKER
RIGHT REAR MID-RANGE SPEAKER
RIGHT SIDE SECTION ANTENNA AMPLIFIER
RIGHT SUB- WOOFER
ROOF ANTENNA 2
SAT
SATELLITE RECEIVER (LEFT SIDE OF REAR COMPT)
TCU
TELEPHONE RETROFIT PACKAGES CONNECTOR
TELEPHONE TRANSCEIVER (CENTER OF REAR COMPT)
WHT WIRE
WHT/BRN WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> Radio circuit, convertible with base radio -> NCA WIRE
Wiring diagram nca (56 of 89)
1 2 (PIN 5-10 NOT USED)
BISTABLE RELAY
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
CAR INFORMATION COMPUTER CIC
CD CHANGER (LEFT SIDE OF REAR COMPT)
CENTRAL INFORMATION DISPLAY
COMPUTER DATA LINES SYSTEM
DIGITAL TUNER US (DAB)
ELECTRONICS JUNCTION BOX
FUSE
GRN WIRE
GRY/RED WIRE
HOT AT ALL TIMES
JUNCTION BOX (UNDER RIGHT SIDE OF DASH)
MOST-BUS CONNECTOR
NCA WIRE
OBDII SOCKET
ON LEFT IN BUMPER TV ANTENNA
ON RIGHT IN BUMPER TV ANTENNA
ORG/ WIRE
ORG/GRN WIRE
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/YEL WIRE
ROOF ANTENNA
TELEPHONE TRANSCEIVER
USB PORT
VIDEO MODULE (LEFT SIDE OF REAR COMPT)
WHT WIRE
YEL WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> Radio circuit, convertible with car information computer, base radio (1 of 2) -> NCA WIRE
Wiring diagram nca (57 of 89)
AMPLIFIER
ANTENNA DIVERSITY
BLK WIRE
BLK/BLU WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/WHT WIRE
BRN WIRE
CONVERTIBLE TOP MODULE
FM ANTENNA 1
FM ANTENNA 2
FM ANTENNA 3
FM ANTENNA 4
FUSE 18
FUSE 19
GRN WIRE
JUNCTION BOX (UNDER RIGHT SIDE OF DASH)
LEFT FRONT MID-RANGE SPEAKER
LEFT REAR MID-RANGE SPEAKER
LEFT SIDE SECTION ANTENNA
LEFT SUB- WOOFER
NCA WIRE
REAR WINDOW ANTENNA AMPLIFIER
REAR-WINDOW AERIAL
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RIGHT FRONT MID-RANGE SPEAKER
RIGHT REAR MID-RANGE SPEAKER
RIGHT SIDE SECTION ANTENNA AMPLIFIER
RIGHT SUB- WOOFER
ROOF ANTENNA 2
SAT
SATELLITE RECEIVER (LEFT SIDE OF REAR COMPT)
WHT WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> Radio circuit, convertible with car information computer, base radio (2 of 2) -> NCA WIRE
Wiring diagram nca (58 of 89)
1 2 (PIN 3-10 NOT USED)
BISTABLE RELAY
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BLU/YEL WIRE
BRN WIRE
BRN/ORG WIRE
CAR INFORMATION COMPUTER CIC
CD CHANGER (LEFT SIDE OF REAR COMPT)
CENTRAL INFORMATION DISPLAY
COMPUTER DATA LINES SYSTEM
DIGITAL TUNER US (DAB)
ELECTRONICS JUCNTION BOX
FUSE
FUSE 18
FUSE 19
GRN WIRE
GRY/RED WIRE
HOT AT ALL TIMES
JUNCTION BOX (UNDER RIGHT SIDE OF DASH)
MOST-BUS CONNECTOR
NCA WIRE
OBDII SOCKET
ON LEFT IN BUMPER TV ANTENNA
ON RIGHT IN BUMPER TV ANTENNA
ORG/ WIRE
ORG/GRN WIRE
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/YEL WIRE
ROOF ANTENNA
TCU 1 2
USB PORT
VIDEO MODULE (LEFT SIDE OF REAR COMPT)
WHT WIRE
YEL WIRE
YEL/BLK WIRE
YEL/RED WIRE
Go to component -> Radio circuit, convertible with car information computer, hifi radio (1 of 2) -> NCA WIRE
Wiring diagram nca (59 of 89)
AMPLIFIER (LEFT SIDE OF REAR COMPT)
ANTENNA DIVERSITY
BLK WIRE
BLK/BLU WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU/BLK WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRN WIRE
BRN/ORG WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CONVERTIBLE TOP MODULE
FM ANTENNA 1
FM ANTENNA 2
FM ANTENNA 3
FM ANTENNA 4
FUSE 15
GRN WIRE
GRY WIRE
JUNCTION BOX (UNDER RIGHT SIDE OF DASH)
LEFT FRONT MID-RANGE SPEAKER
LEFT FRONT TWEETER
LEFT REAR HI-RANGE SPEAKER
LEFT REAR MID-RANGE SPEAKER
LEFT SIDE SECTION ANTENNA AMPLIFIER
LEFT SUBWOOFER
NCA WIRE
REAR WINDOW ANTENNA AMPLIFIER
REAR-WINDOW AERIAL
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRY WIRE
RED/WHT WIRE
RELAY ENERGIZED
RIGHT FRONT MID-RANGE SPEAKER
RIGHT FRONT TWEETER
RIGHT REAR HI-RANGE SPEAKER
RIGHT REAR MID-RANGE SPEAKER
RIGHT SIDE SECTION ANTENNA AMPLIFIER
RIGHT SUBWOOFER
ROOF ANTENNA 2
SAT
SATELLITE RECEIVER (LEFT SIDE OF REAR COMPT)
WHT WIRE
YEL/BLK WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> Radio circuit, convertible with car information computer, hifi radio (2 of 2) -> NCA WIRE
Wiring diagram nca (60 of 89)
1 2 (PIN 3-10 NOT USED)
BISTABLE RELAY
BLK WIRE
BLU WIRE
BLU/RED WIRE
BLU/YEL WIRE
BRN WIRE
CAR INFORMATION COMPUTER CIC
CD CHANGER (LEFT SIDE OF REAR COMPT)
CENTRAL INFORMATION DISPLAY ROOF ANTENNA
COMPUTER DATA LINES SYSTEM
ELECTRONICS JUCNTION BOX
FUSE
FUSE 18
FUSE 19
GRN WIRE
GRY/RED WIRE
HOT AT ALL TIMES
JUNCTION BOX (UNDER RIGHT SIDE OF DASH)
MOST-BUS CONNECTOR
NCA WIRE
OBDII SOCKET
ON LEFT IN BUMPER TV ANTENNA
ON RIGHT IN BUMPER TV ANTENNA
ORG/ WIRE
ORG/GRN WIRE
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/YEL WIRE
ROOF ANTENNA 2
SAT
SATELLITE RECEIVER (LEFT SIDE OF REAR COMPT)
TCU
USB PORT
VIDEO MODULE (LEFT SIDE OF REAR COMPT)
WHT WIRE
YEL WIRE
Go to component -> Radio circuit, convertible with car information computer, top hifi radio (1 of 2) -> NCA WIRE
