BMW 1 series E81/E82/E87/E88 facelift (2007-2011) interference suppression capacitor for ignition coils Wiring diagram
This page shows the only wiring diagram for the component.interference suppression capacitor for ignition coils, which is found in the car BMW 1 series E81/E82/E87/E88 facelift (2007-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram interference suppression capacitor for ignition coils (1 of 1)
BRN WIRE
CRANKSHAFT BREATHER HEATING 1
CRANKSHAFT BREATHER HEATING 2
DISA CONTROLLER
DME CONTROL MODULE
FUEL INJECTORS RELAY
IGNITION COIL 1
IGNITION COIL 3
IGNITION COIL 4
IGNITION COIL 5
IGNITION COIL 6
IGNITION IGNITION COIL 1 COIL 2
IGNITION IGNITION COIL 3 COIL 2
INTERFERENCE SUPPRESSION CAPACITOR FOR IGNITION COILS
NCA WIRE
OIL CONDITION SENSOR
REFRIGERANT COMPRESSOR CONTROL VALVE
REVERSING LIGHT SWITCH
TOP OF ENGINE)
TRANSMISSION CONTROL
Go to component: -> Ground distribution circuit (4 of 4) -> INTERFERENCE SUPPRESSION CAPACITOR FOR IGNITION COILS
