BMW 1 series E81/E82/E87/E88 facelift (2007-2011) intake temperature boost pressure sensor Wiring diagram

This page shows the only wiring diagram for the component.intake temperature boost pressure sensor, which is found in the car BMW 1 series E81/E82/E87/E88 facelift (2007-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram intake temperature boost pressure sensor (1 of 1)

Wiring diagram intake temperature boost pressure sensor for BMW 1 series E81/E82/E87/E88 facelift (2007-2011)

Get access

BLK/BLU WIRE BLK/GRN WIRE BLK/RED WIRE BLK/VIO WIRE BLK/YEL WIRE BLU WIRE BLU/YEL WIRE BRN WIRE BSD SIG CYL CYL 4-6 1-3 DME CONTROL MODULE (RIGHT REAR OF ENGINE COMPT) DME RLY DOUBLE KNOCK SENSOR (LEFT SIDE OF ENGINE) ELECTRIC THROTTLE ACTUATOR FUEL TANK SIG INTAKE PIPE PRESSURE SENSOR (TOP LEFT SIDE OF ENGINE) INTAKE TEMPERATURE BOOST PRESSURE SENSOR NCA WIRE NEUTRAL SENSOR ORG/ WIRE RED WIRE RED/BLK WIRE RED/GRY WIRE SENSOR SENSOR GRD SENSOR SIG THROTTLE THROTTLE GRD THROTTLE SIG VIO WIRE VOL CNTRL WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/YEL WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/RED WIRE

Go to component: -> Wiring diagram engine performance 3.0l twin turbo (3 of 4) -> INTAKE TEMPERATURE BOOST PRESSURE SENSOR
