BMW 1 series E81/E82/E87/E88 facelift (2007-2011) fuse 74 fuse 56 Wiring diagram

ACTIVE CRUISE CONTROL BISTABLE RELAY BLK/RED WIRE BLU WIRE BRN WIRE COMFORT DRIVER'S SIDE OUTER ACCESS DOOR HANDLE CONTROL ELECTRONIC MODULE MODULE DC/DC CONVERTER DRIVER'S LUMBAR SUPPORT SWITCH DRIVER'S LUMBAR SUPPORT VALVE BLOCK DRIVER'S SEAT BACKREST WIDTH ADJUSTMENT SWITCH DRIVER'S SEAT BACKREST WIDTH ADJUSTMENT VALVE BLOCK EJECT TCU BOX ELECTRONICS JUNCTION BOX FOOTWELL TRAILER MODULE MODULE FROM CAR ACCESS SYSTEM (DIAGRAM 3 OF 5) FROM FUSE 28 (JUNCTION BOX) (DIAGRAM 3 OF 5) FROM FUSE 6 JUNCTION BOX (DIAGRAM 4 OF 5) FROM FUSE 70 (DIAGRAM 4 OF 5) FROM FUSE 85 (DIAGRAM 3 OF 5) FROM FUSE 85 (JUNCTION BOX) (DIAGRAM 3 OF 5) FUSE 20 FUSE 21 FUSE 22 FUSE 23 FUSE 32 FUSE 59 FUSE 61 FUSE 74 FUSE 56 FUSE 86 FUSE 31 FUSE 88 (DIAGRAM 4 OF 5) GRN WIRE INDEPENDENT/ AUXILIARY HEATING CONTROL MODULE INSTRUMENT CLUSTER CCC/M CONTROL ASK MODULE JUNCTION BOX (UNDER RIGHT NCA WIRE PASSENGER'S LUMBAR SUPPORT SWITCH PASSENGER'S LUMBAR SUPPORT VALVE BLOCK PASSENGER'S SEAT BACKREST ADJUSTMENT SWITCH PASSENGER'S SEAT BACKREST ADJUSTMENT VALVE BLOCK PASSENGER'S SIDE OUTER DOOR HANDLE ELECTRONIC MODULE RED WIRE RED/BLK WIRE RED/BRN WIRE RED/GRN WIRE RED/WHT WIRE RED/WHT/YEL WIRE RED/YEL WIRE SIDE OF DASH) TO FUSE 24 (DIAGRAM 3 OF 5) TRAILER MODULE TRANSMISSION CONTROL VIO WIRE WHT WIRE YEL WIRE
