BMW 1 series E81/E82/E87/E88 facelift (2007-2011) fuse 70 Wiring diagram
This page shows the only wiring diagram for the component.fuse 70, which is found in the car BMW 1 series E81/E82/E87/E88 facelift (2007-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fuse 70 (1 of 1)
AUC SENSOR
BLK WIRE
BLOWER OUTPUT STAGE
BLU WIRE
BRN WIRE
DRIVER'S SEAT HEATING MODULE
DRIVER'S SWITCH CLUSTER
ELECTRONICS JUNCTION BOX
FROM CAR ACCESS SYSTEM (DIAGRAM 3 OF 5)
FROM FUSE 30 (DIAGRAM 3 OF 5)
FROM HORN RELAY (DIAGRAM 4 OF 5)
FRONT CIGAR LIGHTER
FUEL PUMP CONTROL (EKPS)
FUSE 10
FUSE 57
FUSE 6
FUSE 65
FUSE 66
FUSE 7
FUSE 70
FUSE 77
FUSE 8
FUSE 88
FUSE 9
GEAR INDICATOR LIGHTING
GLOVE COMPARTMENT LIGHT
GRN WIRE
GRY WIRE
HEATING/AIR CONDITIONING SYSTEM
HORN RELAY
JUNCTION BOX
LONGITUDINAL DYNAMICS MANAGEMENT
LUGGAGE COMPARTMENT SOCKET OUTLET
NCA WIRE
PARK DISTANCE CONTROL (PDC)
PASSENGER'S SEAT HEATING MODULE
PASSENGER'S SIDE OUTSIDE MIRROR
REAR CENTER CONSOLE CHARGING SOCKET
RED WIRE
RIGHT LEFT HORN HORN
RIGHT LUGGAGE COMPARTMENT LIGHT
ROOF FUNCTION CONTROL CENTER
TELEPHONE RETROFIT PACKAGES CONNECTOR
TELEPHONE TRANSCEIVER
TERMINAL 15 RELAY
TO BISTABLE RELAY (DIAGRAM 5 OF 5)
TO DC/DC CONVERTER (DIAGRAM 5 OF 5)
TO FUSE 20 (DIAGRAM 5 OF 5)
TO FUSE 77 (DIAGRAM 4 OF 5)
VIO WIRE
WHT WIRE
YEL WIRE
Go to component: -> Power distribution circuit (4 of 5) -> FUSE 70
