BMW 1 series E81/E82/E87/E88 facelift (2007-2011) footwell trailer module module Wiring diagram
This page shows the only wiring diagram for the component.footwell trailer module module, which is found in the car BMW 1 series E81/E82/E87/E88 facelift (2007-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram footwell trailer module module (1 of 1)
ACTIVE CRUISE CONTROL
BISTABLE RELAY
BLK/RED WIRE
BLU WIRE
BRN WIRE
COMFORT DRIVER'S SIDE OUTER ACCESS DOOR HANDLE CONTROL ELECTRONIC MODULE MODULE
DC/DC CONVERTER
DRIVER'S LUMBAR SUPPORT SWITCH
DRIVER'S LUMBAR SUPPORT VALVE BLOCK
DRIVER'S SEAT BACKREST WIDTH ADJUSTMENT SWITCH
DRIVER'S SEAT BACKREST WIDTH ADJUSTMENT VALVE BLOCK
EJECT TCU BOX
ELECTRONICS JUNCTION BOX
FOOTWELL TRAILER MODULE MODULE
FROM CAR ACCESS SYSTEM (DIAGRAM 3 OF 5)
FROM FUSE 28 (JUNCTION BOX) (DIAGRAM 3 OF 5)
FROM FUSE 6 JUNCTION BOX (DIAGRAM 4 OF 5)
FROM FUSE 70 (DIAGRAM 4 OF 5)
FROM FUSE 85 (DIAGRAM 3 OF 5)
FROM FUSE 85 (JUNCTION BOX) (DIAGRAM 3 OF 5)
FUSE 20
FUSE 21
FUSE 22
FUSE 23
FUSE 32
FUSE 59
FUSE 61
FUSE 74 FUSE 56
FUSE 86 FUSE 31
FUSE 88 (DIAGRAM 4 OF 5)
GRN WIRE
INDEPENDENT/ AUXILIARY HEATING CONTROL MODULE
INSTRUMENT CLUSTER CCC/M CONTROL ASK MODULE
JUNCTION BOX (UNDER RIGHT
NCA WIRE
PASSENGER'S LUMBAR SUPPORT SWITCH
PASSENGER'S LUMBAR SUPPORT VALVE BLOCK
PASSENGER'S SEAT BACKREST ADJUSTMENT SWITCH
PASSENGER'S SEAT BACKREST ADJUSTMENT VALVE BLOCK
PASSENGER'S SIDE OUTER DOOR HANDLE ELECTRONIC MODULE
RED WIRE
RED/BLK WIRE
RED/BRN WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/WHT/YEL WIRE
RED/YEL WIRE
SIDE OF DASH)
TO FUSE 24 (DIAGRAM 3 OF 5)
TRAILER MODULE
TRANSMISSION CONTROL
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (5 of 5) -> FOOTWELL TRAILER MODULE MODULE
