BMW 1 series E81/E82/E87/E88 facelift (2007-2011) driver's side outer door handle electronic module Wiring diagram
This page shows the only wiring diagram for the component.driver's side outer door handle electronic module, which is found in the car BMW 1 series E81/E82/E87/E88 facelift (2007-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver's side outer door handle electronic module (1 of 1)
BLU/GRY WIRE
BLU/YEL WIRE
BRN WIRE
CAR ACCESS SYSTEM (UNDER LEFT SIDE OF DASH)
COMFORT ACCESS CONTROL MODULE (RIGHT SIDE OF REAR COMPT)
COMPUTER DATA LINES SYSTEM
DRIVER'S SIDE OUTER DOOR HANDLE ELECTRONIC MODULE
FRONT INNER ANTENNA CENTER CONSOLE
GRN WIRE
GRY WIRE
GRY/GRN WIRE
GRY/VIO WIRE
GRY/WHT WIRE
GRY/YEL WIRE
ORG/GRN WIRE
PASSENGER'S SIDE OUTER DOOR HANDLE ELECTRONIC MODULE
REAR FENDER AERIAL
REAR INNER ANTENNA LUGGAGE COMPARTMENT
REAR INTERIOR ANTENNA CENTER CONSOLE
RED WIRE
RED/YEL WIRE
SLIDE-IN COMPARTMENT
START-STOP BUTTON
WHT WIRE
WHT/BLK WIRE
WHT/GRN WIRE
Go to component -> Access/start circuit (2 of 2) -> DRIVER'S SIDE OUTER DOOR HANDLE ELECTRONIC MODULE
