BMW 1 series E81/E82/E87/E88 facelift (2007-2011) convertible top lid open hall sensor Wiring diagram
This page shows the only wiring diagram for the component.convertible top lid open hall sensor, which is found in the car BMW 1 series E81/E82/E87/E88 facelift (2007-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram convertible top lid open hall sensor (1 of 1)
AIR CONDITIONING SYSTEM
BLK WIRE
BLK/GRN WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLU WIRE
BLU/YEL WIRE
BRN WIRE
BRN/BLK WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/RED WIRE
BRN/VIO WIRE
COMPUTER DATA LINES SYSTEM
CONVERTIBLE TOP DRIVE
CONVERTIBLE TOP DRIVE VALVE 1
CONVERTIBLE TOP DRIVE VALVE 2
CONVERTIBLE TOP DRIVE VALVE 3
CONVERTIBLE TOP LID OPEN HALL SENSOR
CONVERTIBLE TOP MODULE
CONVERTIBLE TOP RELAY 1
CONVERTIBLE TOP RELAY 2
FUSE
FUSE HOLDER (RIGHT SIDE OF REAR COMPT)
GRN WIRE
GRN/BLK WIRE
GRY WIRE
GRY/BLK WIRE
GRY/GRN WIRE
HOT AT ALL TIMES
JUNCTION BOX (UNDER RIGHT SIDE OF DASH)
NCA WIRE
ORG/GRN WIRE
REAR FUSE
RED WIRE
RED/GRY WIRE
RED/WHT WIRE
RELAY ENERGIZED
WHT/BLK WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/YEL WIRE
YEL/BLK WIRE
YEL/BLU WIRE
YEL/BRN WIRE
YEL/GRN WIRE
YEL/RED WIRE
YEL/VIO WIRE
Go to component: -> Convertible top circuit (1 of 2) -> CONVERTIBLE TOP LID OPEN HALL SENSOR
